Active Pixels:
4x 1944 (H) x 1092 (V)
Image sensor:
5MP 1/2.8" CMOS sensor
Maximum resolution:
5MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.08 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
2592 (H) × 1944 (V)
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Horizontal Field of View (HFOV:
85° ~ 31°
IR Distance:
140' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
24° ~ 62°
Audio compression:
G.711
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input, 1 output
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, SD card recording
Privacy Zones:
16 programmable privacy masks
Shutter Mode:
Auto, Manual, Slow Shutter
Shutter Speed:
8 ~ 1/50000
Slow Shutter Speed:
Off, x15, x2, x3, x4, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP:
IPv4
Network resolution:
H.264: 2.1MP/1080p, 720p (main), CIF (sub), H.264: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, H.265: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, MJPEG: CIF
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security:
802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
32Kbps~20Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
DW Spectrum® IPVMS, ExacqVision Technologies, Genetec Inc., Milestone Systems
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-40°F ~ 122°F (-40°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
*Dimensions based on the position of the sun shield cover, 12.2” x 3.81” (310 x 97mm), 9.4” x 3.8” (264 x 96.7 mm)
Camera Weight:
1.96 lbs (0.89 kg)
Housing:
Bullet
Housing Color:
White
IP rating:
Weather Resistant (IP66)
Materials:
Aluminum die-casting
American wire gauge (AWG:
Cable type #18
Power Consumption:
DC12V: max 9.0W, 750mA, PoE: max 10.5W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
