Panduit PUP6XHD04RD-G Cat6 Plenum Bulk Cable

The Panduit PUP6XHD04RD-G delivers 1,000 feet of plenum-rated Category 6 U/UTP cable in a red jacket, purpose-built for commercial integrators running horizontal cabling in air-handling spaces. This 23 AWG solid copper cable meets CMP flammability standards, supports 10GBASE-T Ethernet up to 55 meters, and provides the color-coding and code-compliance security and IT installers need for large-scale infrastructure deployments. Whether you're running IP camera drops, access control readers, or structured cabling for a datacenter buildout, this pull box delivers contractor quantities of Panduit-grade copper in a jacket engineered for above-ceiling and HVAC plenum environments.

Key Features

• Plenum-rated (CMP) jacket meets NFPA 262 and NEC Article 770 for installation in air-handling spaces without conduit
• Category 6 performance: 250 MHz bandwidth, 10GBASE-T capable up to 55m, Gigabit Ethernet to 100m
• 23 AWG solid bare copper conductors for permanent horizontal runs and reliable termination into keystone jacks, patch panels, and 110 blocks
• U/UTP (unshielded twisted pair) construction balances cost and performance for most commercial environments
• 1,000-foot pull box (305 meters) covers typical horizontal cable runs with minimal splicing
• Red jacket for color-coded network segmentation — ideal for security/surveillance VLANs, fire alarm, or critical infrastructure circuits
• TIA-568.2-D and ISO/IEC 11801 compliant for standards-based structured cabling systems
• PoE++ (IEEE 802.3bt Type 4) compatible: supports up to 100W for high-power IP cameras, PTZ domes, and PoE lighting

Plenum spaces — the areas above drop ceilings and below raised floors used for HVAC return air — require cable with strict fire and smoke ratings. Standard PVC-jacketed cable releases toxic smoke and fuels fire spread; plenum cable uses low-smoke, flame-retardant compounds that self-extinguish and limit combustion byproducts. The PUP6XHD04RD-G's CMP (Communications Plenum) rating meets NFPA 262 flame-propagation limits and NEC Article 770 requirements, letting you pull cable through plenums, ducts, and air-handling spaces without metal conduit or fireproof enclosures. This eliminates the labor and material cost of conduit runs while maintaining full code compliance — critical for commercial security installs where above-ceiling camera drops, door controllers, and wireless AP runs are the norm. Building inspectors and fire marshals expect plenum cable in these zones; using non-plenum jacketed cable in air-handling spaces is a code violation that can halt occupancy permits and trigger costly rework.

Category 6 remains the backbone of modern IP infrastructure. The PUP6XHD04RD-G's 250 MHz bandwidth and four-pair twisted-pair geometry support 10 Gigabit Ethernet (10GBASE-T) up to 55 meters and Gigabit Ethernet (1000BASE-T) to the full 100-meter horizontal limit defined by TIA-568. For security integrators, this headroom matters: 4K and 8MP IP cameras push 20-50 Mbps sustained; multichannel intercom stations, access control panels with PoE locks, and AI-powered analytics appliances all expect reliable Gigabit links. Cat6 future-proofs the infrastructure — a properly terminated Cat6 link installed today will support the next generation of 12MP cameras, Wi-Fi 7 access points, and multi-gig PoE devices without a forklift upgrade. The cable also supports Power over Ethernet up to 100 watts (IEEE 802.3bt Type 4 / PoE++), enabling single-cable deployment of PTZ cameras, outdoor-rated illuminators, and high-power wireless bridges without separate AC circuits or midspan injectors.

The 23 AWG solid bare copper conductors are engineered for permanent installation and tool-based termination. Solid conductors (versus stranded) maintain consistent DC loop resistance over long pulls, deliver lower attenuation, and seat cleanly into insulation-displacement connectors (IDC) on keystone jacks, patch panels, and 110 punchdown blocks. This is the correct cable type for horizontal structured cabling — the in-wall and above-ceiling segments that connect telecom rooms to work-area outlets. Stranded patch cables handle the flexible connections at endpoints; solid backbone cable like the PUP6XHD04RD-G handles the fixed infrastructure. The U/UTP construction (unshielded twisted pairs with no overall foil or braid) keeps costs down and simplifies termination — no drain wires to land, no shielding to bond — while still delivering the crosstalk performance needed for most commercial and datacenter environments. For installations near high-EMI sources (motor controllers, elevator shafts, radio transmitters), consider Panduit's F/UTP or S/FTP shielded variants; for typical office, retail, and security camera runs, U/UTP provides the best balance of cost, performance, and ease of installation.

The red jacket serves a practical function: network segmentation and visual identification. Many integrators color-code infrastructure by function — blue for data, yellow for VoIP, red for security/surveillance, orange for building automation. A surveillance VLAN running on red-jacketed Cat6 becomes immediately obvious in a crowded telecom rack or above-ceiling junction, reducing troubleshooting time and preventing accidental cross-connects during MAC (moves, adds, changes). Fire alarm and life-safety systems also frequently spec red-jacketed cable to meet AHJ (authority having jurisdiction) requirements for visual distinction from commercial IT circuits. The 1,000-foot pull box is the contractor standard — enough cable to cover multiple drops on a single floor without mid-run splicing, packaged in a dispenser box that feeds cleanly through cable trays and J-hooks without tangling or kinking.

Panduit's Pan-Net copper cable line is third-party tested and certified to TIA-568.2-D and ISO/IEC 11801 Category 6 channel and permanent-link specs, backed by Panduit's system warranty when installed as part of a complete Panduit infrastructure solution (cable, jacks, patch panels, patch cords). For security integrators and IT contractors running hundreds of drops across multi-building campuses, healthcare facilities, K-12 schools, or datacenter expansions, the PUP6XHD04RD-G delivers the plenum-rated, color-coded, standards-compliant Cat6 copper you need to pass inspection, support current and future IP devices, and maintain the install quality that keeps callbacks and warranty claims at zero.
