Bosch MIC-7604-Z12GR vs Bosch NDP-7804-Z12L: Specification Comparison
Both the Bosch MIC-7604-Z12GR and the NDP-7804-Z12L are 8MP PTZ cameras from Bosch's 7100i platform, sharing the same resolution class, frame rate, and 12x optical zoom varifocal lens. A buyer evaluating perimeter or wide-area surveillance coverage would reasonably cross-shop these two models. The key differentiators lie in their deployment environment, enclosure design, IR wavelength, multi-stream count, PoE class, and operating temperature ceiling — all of which are spec-documented and examined below.
In This Guide
How do the imaging specs compare?
Both cameras share a 1-inch CMOS sensor, 8MP resolution at 30 fps, and an identical 9.3–111.6 mm varifocal lens delivering 12x optical zoom. Wide dynamic range is 62 dB on both models. Minimum color illumination is 0.292 Lux on the MIC-7604-Z12GR versus 0.2998 Lux on the NDP-7804-Z12L — a negligible real-world difference. In B/W mode, the MIC-7604-Z12GR is specified at 0.011 Lux; the NDP-7804-Z12L lists 0 Lux B/W, indicating a true starlight or IR-assisted near-zero threshold, though the methodology behind that 0 Lux figure is not further detailed in the provided specs.
IR implementation differs between the two. The MIC-7604-Z12GR uses 940 nm invisible IR illumination, which avoids the visible red glow associated with standard IR but typically yields a shorter effective range for the same emitter power. The NDP-7804-Z12L uses 850 nm IR, the more common wavelength that generally provides greater illumination distance and is more widely characterized in spec sheets. Neither product's provided specs state a numeric IR range in meters, so a direct distance comparison cannot be made from the data supplied.
What about installation and environment?
The MIC-7604-Z12GR carries an IP67 ingress rating (full dust-tight, immersion to 1 m) and IK10 impact resistance, with an operating temperature range of -40 °C to +65 °C (-40 °F to +149 °F). The NDP-7804-Z12L is rated IP66 (dust-tight, powerful water jets) and IK10, with a narrower operating ceiling of -40 °C to +50 °C (-40 °F to +122 °F). For installations subject to extreme heat — rooftops, desert climates, or enclosed industrial enclosures — the MIC-7604-Z12GR's 15 °C higher upper temperature limit is a material advantage.
Power delivery also differs. The MIC-7604-Z12GR is powered by PoE 802.3af (Class 3, max 15.4 W at the PSE), while the NDP-7804-Z12L requires PoE++ 802.3bt (up to 90 W at the PSE), reflecting its heavier aluminum housing, higher-power IR array, and additional processing demands. Installers must verify switch or injector compatibility accordingly — 802.3bt infrastructure is not universally deployed. Mounting options are nearly identical (wall, pole, corner, rack) with the NDP-7804-Z12L adding a pendant mount option not listed for the MIC-7604-Z12GR. The NDP-7804-Z12L's physical dimensions are specified at 210.65 mm diameter × 324 mm height, weighing 5.80 kg; equivalent dimensions and weight are not provided in the MIC-7604-Z12GR specs.
Which fits your VMS and analytics better?
Both cameras support ONVIF, H.265/H.264/MJPEG compression, cloud connectivity, local microSD/SDHC/SDXC storage, built-in audio input, alarm I/O, and the same IVA Pro analytics suite (Buildings, Perimeter, Privacy). Intelligent tracking is listed on both. The NDP-7804-Z12L supports 4 simultaneous video streams versus 3 on the MIC-7604-Z12GR — relevant in multi-VMS or redundant-recording architectures where an additional independent stream (e.g., a low-res mobile feed) is required without transcoding.
The MIC-7604-Z12GR spec notes ONVIF Profile M and encryption spanning TLS 1.0/1.1/1.2 plus AES-128/AES-256. The NDP-7804-Z12L lists TLS 1.2 and TLS 1.3 plus AES-128/AES-256 — dropping the legacy TLS 1.0/1.1 support, which is preferable from a cybersecurity hardening standpoint. Both cameras are confirmed NDAA compliant. People Counting analytics is listed explicitly only in the MIC-7604-Z12GR spec data; it is not listed for the NDP-7804-Z12L from the provided specs, though absence from the provided data does not conclusively confirm absence from the product.
Which should you choose: the MIC-7604-Z12GR or the NDP-7804-Z12L?
Our take: The MIC-7604-Z12GR is the stronger choice when the installation demands a higher operating temperature ceiling, a lower PoE infrastructure investment, and invisible 940 nm IR. Its -40 °C to +65 °C range beats the NDP-7804-Z12L's +50 °C ceiling by 15 °C — a decisive factor in hot-climate or rooftop deployments. It also runs on standard 802.3af PoE, reducing switch and cabling upgrade costs versus the NDP-7804-Z12L's 802.3bt requirement. Conversely, the NDP-7804-Z12L is preferable when a fourth simultaneous video stream is required, when modern-only TLS 1.2/1.3 encryption is mandated by security policy, or when a pendant-mount form factor is necessary. Both cameras are otherwise spec-matched on resolution, lens, WDR, analytics suite, and IK10 impact resistance. Platform qualifier: confirm VMS compatibility with each model's ONVIF profile before specifying either.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Bosch MIC-7604-Z12GR | Bosch NDP-7804-Z12L |
|---|---|---|
| Resolution | 8MP (4K) | 8MP (4K) |
| Frame Rate | 30 fps @ 8MP | 30 fps @ 8MP |
| Image Sensor | 1" CMOS | 1" CMOS |
| Focal Length / Zoom | 9.3–111.6 mm / 12x optical | 9.3–111.6 mm / 12x optical |
| Min. Illumination (Color) | 0.292 Lux | 0.2998 Lux |
| Min. Illumination (B/W) | 0.011 Lux | 0 Lux |
| IR Wavelength | 940 nm (invisible) | 850 nm |
| Wide Dynamic Range | 62 dB | 62 dB |
| Video Compression | H.265 / H.264 / MJPEG | H.265 / H.264 / MJPEG |
| Multi-Streaming | 3 streams | 4 streams |
| IP Rating | IP67 | IP66 |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | -40 °C to +65 °C | -40 °C to +50 °C |
| Power Input / PoE Class | PoE 802.3af | PoE++ 802.3bt |
| Edge Storage | microSD / SDHC / SDXC | microSD / SDHC / SDXC |
| Audio | Built-in audio input | Built-in audio input |
| ONVIF | Yes (Profile M noted) | Yes |
| NDAA Compliant | Yes | Yes |
| Encryption | TLS 1.0 / 1.1 / 1.2; AES-128 / AES-256 | TLS 1.2 / 1.3; AES-128 / AES-256 |
| Mounting Options | Wall / Pole / Corner / Rack | Wall / Pole / Pendant / Corner / Rack |
| Dimensions | — | 210.65 mm dia. x 324 mm H |
| Weight | — | 5.80 kg |
| Housing Material | — | Aluminum |
| Warranty | Manufacturer Warranty | Manufacturer Warranty |
Frequently Asked Questions
Which should you choose: the MIC-7604-Z12GR or the NDP-7804-Z12L?
The MIC-7604-Z12GR is the stronger choice when the installation demands a higher operating temperature ceiling, a lower PoE infrastructure investment, and invisible 940 nm IR. Its -40 °C to +65 °C range beats the NDP-7804-Z12L's +50 °C ceiling by 15 °C — a decisive factor in hot-climate or rooftop deployments. It also runs on standard 802.3af PoE, reducing switch and cabling upgrade costs versus the NDP-7804-Z12L's 802.3bt requirement. Conversely, the NDP-7804-Z12L is preferable when a fourth simultaneous video stream is required, when modern-only TLS 1.2/1.3 encryption is mandated by security policy, or when a pendant-mount form factor is necessary. Both cameras are otherwise spec-matched on resolution, lens, WDR, analytics suite, and IK10 impact resistance. Platform qualifier: confirm VMS compatibility with each model's ONVIF profile before specifying either.
Is the MIC-7604-Z12GR or NDP-7804-Z12L better for low-light performance?
On the provided specs, both cameras are very close in color low-light sensitivity — 0.292 Lux (MIC-7604-Z12GR) versus 0.2998 Lux (NDP-7804-Z12L). The NDP-7804-Z12L lists 0 Lux in B/W mode versus 0.011 Lux for the MIC-7604-Z12GR, suggesting a potential edge in near-zero-light conditions, though the basis for the 0 Lux figure is not detailed in the supplied specs. IR wavelength also differs: 940 nm (invisible) on the MIC-7604-Z12GR versus 850 nm on the NDP-7804-Z12L; 850 nm typically delivers greater illumination range for equivalent emitter power. A numeric IR distance spec is not provided for either model.
Do both cameras work with existing 802.3af PoE switches?
No. The MIC-7604-Z12GR is powered by standard PoE 802.3af and will work with most existing PoE switches and injectors. The NDP-7804-Z12L requires PoE++ 802.3bt, which supplies significantly higher wattage and is not supported by standard 802.3af or 802.3at (PoE+) infrastructure. Installers specifying the NDP-7804-Z12L must verify that their switches or midspan injectors support 802.3bt before deployment.
Which camera is better suited for extreme-heat outdoor environments?
The MIC-7604-Z12GR is the better choice for high-temperature environments, with an upper operating limit of +65 °C (+149 °F) compared to the NDP-7804-Z12L's +50 °C (+122 °F) ceiling. The 15 °C difference is significant for rooftop, desert, or industrial deployments where ambient temperatures can exceed 50 °C. Both cameras share the same lower bound of -40 °C, so cold-climate performance is equivalent per the provided specs.
