Bosch MIC-7522-Z30G vs Bosch MIC-7602-Z30WR: Specification Comparison
Both the Bosch MIC-7522-Z30G and MIC-7602-Z30WR are outdoor-rated, 2MP PTZ cameras from the MIC 7100i platform, sharing the same 30x optical zoom lens, 1/2" CMOS sensor, IK10 impact rating, and IP67 weatherproofing. They target the same PTZ surveillance segment and are genuine cross-shop candidates. The primary differences lie in their analytics engine generation (Intelligent Video Analytics vs. IVA Pro), maximum frame rate, on-board storage, and housing color designation, which may influence platform selection and operational use case.
In This Guide
How do the imaging specs compare?
Both cameras share the same core optical and sensor architecture: a 1/2" CMOS imager, a 30x motorized varifocal lens spanning 6.6–198mm, and identical minimum illumination figures of 0.0047 lux (color) and 0.0013 lux (B&W). Wide Dynamic Range is 120dB on both units, and both feature IR illumination at 940nm (invisible) with automatic day/night switching. In these respects the two models are functionally equivalent at the sensor and optics level.
The one meaningful imaging-layer difference is maximum frame rate. The MIC-7522-Z30G is specified at 60fps at 1080p, while the MIC-7602-Z30WR is specified at 30fps at 1080p. For applications requiring smooth tracking of fast-moving subjects—vehicle capture, crowd monitoring, or forensic zoom during an incident—the 7522's 60fps ceiling is a concrete advantage. Both cameras support H.265, H.264, and MJPEG compression and deliver three simultaneous streams.
What about installation and environment?
Both cameras carry IP67 dust and water ingress protection and IK10 vandal resistance (20-joule impact rating), making both suitable for exposed outdoor deployments. Operating temperature range is identical: -40°C to +65°C (-40°F to +149°F). Power input is PoE (802.3af) on both units. The MIC-7522-Z30G specifies a rack mount type in its fields; the MIC-7602-Z30WR lists wall, pole, corner, and rack as mount types—indicating broader documented mounting flexibility for the 7602, though the 7522's mounting options beyond rack are not fully enumerated in the provided specifications.
Housing color differs: the MIC-7522-Z30G is grey (product name confirms 'Grey') while the MIC-7602-Z30WR is white. This is a deployment aesthetic consideration rather than a functional one, but relevant for site-specific blending requirements. Both carry NDAA compliance and manufacturer warranty; neither spec sheet lists specific warranty duration beyond that designation.
Which fits your VMS and analytics better?
Both cameras are ONVIF-compliant. The MIC-7602-Z30WR explicitly lists ONVIF Profile M in its specs, while the MIC-7522-Z30G lists ONVIF support without specifying a profile. Both support cloud integration and include built-in audio input and alarm inputs/outputs. The analytics generation is the key differentiator: the MIC-7522-Z30G runs Bosch Intelligent Video Analytics (IVA), with people counting noted in the spec fields. The MIC-7602-Z30WR runs IVA Pro, with three distinct licensed modules listed—IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy—representing a more advanced, scene-specific analytics tier.
On-board storage is available only on the MIC-7602-Z30WR, which supports microSD/SDHC/SDXC cards. The MIC-7522-Z30G has no local storage specified. For edge-recording, standalone failover, or direct-to-card operation in bandwidth-constrained environments, the 7602 holds a clear advantage. Encryption capabilities differ slightly: the 7522 lists TLS 1.0–1.2, DES, 3DES, AES, and SSL; the 7602 lists TLS 1.0–1.2, AES128, and AES256—the 7602's spec omits the legacy DES/3DES ciphers, which may be preferred in hardened security environments.
Which should you choose: the MIC-7522-Z30G or the MIC-7602-Z30WR?
Our take: The MIC-7522-Z30G is the stronger choice when high-frame-rate capture is operationally critical, delivering 60fps at 1080p versus the MIC-7602-Z30WR's 30fps ceiling—a 2× difference that matters for fast-moving subject tracking or forensic detail during PTZ zoom. However, the MIC-7602-Z30WR leads in three areas: it provides IVA Pro analytics (Buildings, Perimeter, and Privacy modules versus the 7522's base IVA), it includes microSD/SDHC/SDXC local storage absent on the 7522, and it explicitly documents ONVIF Profile M compliance. For integrators deploying on platforms that leverage Bosch IVA Pro licensing, require edge recording as a failover, or operate in environments where advanced perimeter or privacy masking analytics are mandatory, the MIC-7602-Z30WR is the appropriate specification. If the deployment priority is smooth motion capture at maximum frame rate and local storage is handled at the NVR level, the MIC-7522-Z30G is the correct selection.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Bosch MIC-7522-Z30G | Bosch MIC-7602-Z30WR |
|---|---|---|
| Resolution | 2MP (1920×1080) | 2MP (1920×1080) |
| Image Sensor | 1/2" CMOS | 1/2" CMOS |
| Lens / Focal Length | 30x motorized varifocal, 6.6–198mm | 30x motorized varifocal, 6.6–198mm |
| Max Frame Rate | 60fps @ 1080p | 30fps @ 1080p |
| Min. Illumination (Color) | 0.0047 lux | 0.0047 lux |
| Min. Illumination (B/W) | 0.0013 lux | 0.0013 lux |
| IR Illumination | 940nm invisible IR, auto day/night | 940nm invisible IR, auto day/night |
| Wide Dynamic Range | 120dB | 120dB |
| Video Compression | H.265, H.264, MJPEG | H.265, H.264, MJPEG |
| Multi-Streaming | 3 streams | 3 streams |
| IP Rating | IP67 | IP67 |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | -40°C to +65°C (-40°F to +149°F) | -40°C to +65°C (-40°F to +149°F) |
| Power Input | PoE (802.3af) | PoE (802.3af) |
| Edge / Local Storage | — | microSD / SDHC / SDXC |
| Video Analytics | Intelligent Video Analytics (IVA) | IVA Pro Buildings, IVA Pro Perimeter, IVA Pro Privacy |
| ONVIF | Yes (profile not specified) | Yes, Profile M |
| Audio | Built-in audio input | Built-in audio input |
| Alarm I/O | Yes | Yes |
| Housing Color | Grey | White |
| NDAA Compliant | Yes | Yes |
| Warranty | Manufacturer Warranty (duration not specified) | Manufacturer Warranty (duration not specified) |
Frequently Asked Questions
Which should you choose: the MIC-7522-Z30G or the MIC-7602-Z30WR?
The MIC-7522-Z30G is the stronger choice when high-frame-rate capture is operationally critical, delivering 60fps at 1080p versus the MIC-7602-Z30WR's 30fps ceiling—a 2× difference that matters for fast-moving subject tracking or forensic detail during PTZ zoom. However, the MIC-7602-Z30WR leads in three areas: it provides IVA Pro analytics (Buildings, Perimeter, and Privacy modules versus the 7522's base IVA), it includes microSD/SDHC/SDXC local storage absent on the 7522, and it explicitly documents ONVIF Profile M compliance. For integrators deploying on platforms that leverage Bosch IVA Pro licensing, require edge recording as a failover, or operate in environments where advanced perimeter or privacy masking analytics are mandatory, the MIC-7602-Z30WR is the appropriate specification. If the deployment priority is smooth motion capture at maximum frame rate and local storage is handled at the NVR level, the MIC-7522-Z30G is the correct selection.
Is the MIC-7522-Z30G or MIC-7602-Z30WR better for low-light performance?
Both cameras are specified identically for low-light: 0.0047 lux (color) and 0.0013 lux (B&W) minimum illumination, the same 1/2" CMOS sensor, and the same 940nm IR illumination with automatic day/night switching. Neither model has a low-light advantage over the other based on the provided specifications.
Does either camera support on-board recording without an NVR?
Only the MIC-7602-Z30WR supports local on-board storage, via microSD, SDHC, or SDXC cards. The MIC-7522-Z30G does not list any local storage capability in its specifications, making it dependent on a networked recorder or NVR for video retention.
Which camera has more advanced video analytics—the MIC-7522-Z30G or MIC-7602-Z30WR?
The MIC-7602-Z30WR carries the more advanced analytics engine. It is specified with Bosch IVA Pro in three scene-specific modules: IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy. The MIC-7522-Z30G is specified with Bosch Intelligent Video Analytics (IVA), which is the prior-generation analytics platform. Both list people counting in their feature fields.
