Bosch MIC-7522-Z30BR vs Bosch MIC-7602-Z30WR: Specification Comparison
Both the Bosch MIC-7522-Z30BR and MIC-7602-Z30WR are 2MP outdoor PTZ cameras from the MIC 7100i platform, sharing the same 30x motorized zoom lens, 1/2" CMOS sensor, and IK10-rated housing. The primary differences lie in housing color, analytics engine, and maximum frame rate. Installers and IT buyers evaluating these two models are typically choosing between Bosch's Starlight 7100i (7522) and Inteox 7100i (7602) sub-platforms — a distinction that carries meaningful implications for analytics depth and integration flexibility.
In This Guide
How do the imaging specs compare?
Both cameras use a 1/2" CMOS sensor with identical minimum illumination figures: 0.0047 Lux in color and 0.0013 Lux in black-and-white. Both share a 30x motorized varifocal lens spanning 6.6–198mm and a 120dB Wide Dynamic Range rating. Infrared illumination on both units uses 940nm (invisible) IR with automatic day/night switching. At the sensor and optics level, these two cameras are effectively identical.
The one measurable imaging difference is maximum frame rate: the MIC-7522-Z30BR is rated at 60fps at 1080p, while the MIC-7602-Z30WR is rated at 30fps at 1080p. For applications requiring smooth motion capture of fast-moving subjects — traffic, sports facilities, or high-speed conveyor environments — the 7522's 60fps ceiling is a concrete advantage. For standard surveillance use cases where 30fps is sufficient, the 7602 is not disadvantaged.
What about installation and environment?
Both cameras carry IP67 weatherproofing and IK10 vandal/impact resistance, making both suitable for exposed outdoor deployment. Operating temperature range is identical on both: -40°C to +65°C (-40°F to 149°F). Both are powered via PoE (802.3af) and support wall, pole, corner, and rack mounting configurations.
The primary physical distinction is housing color: the MIC-7522-Z30BR ships in black, and the MIC-7602-Z30WR ships in white. This is an aesthetics and site-blending consideration rather than a functional one. Weight is specified only for the MIC-7522-Z30BR at 8.7 kg (19.2 lb); no weight figure is provided in the supplied specs for the MIC-7602-Z30WR. Both cameras include alarm inputs/outputs per their spec sheets.
Which fits your VMS and analytics better?
Both cameras are ONVIF-compliant, support H.265/H.264/MJPEG compression, deliver 3 simultaneous streams, include built-in audio input, and offer local storage via microSD/SDHC/SDXC. Both support cloud integration and intelligent tracking. The analytics packages diverge significantly: the MIC-7522-Z30BR lists Intelligent Video Analytics (IVA) and People Counting; the MIC-7602-Z30WR, running the Inteox platform, lists IVA Pro Buildings, IVA Pro Perimeter, IVA Pro Privacy, and People Counting — a deeper analytics suite with differentiated scene-type modules.
The MIC-7602-Z30WR also explicitly lists ONVIF Profile M in its specs, which adds metadata streaming support relevant to modern VMS platforms. The MIC-7522-Z30BR's ONVIF profile tier is not specified in the provided data. The Inteox platform on the 7602 is Bosch's open app-based camera OS, which supports third-party analytics app installation — a distinction not reflected in the 7522's spec sheet. Buyers requiring extensible edge analytics or Privacy masking analytics should weigh this difference carefully.
Which should you choose: the MIC-7522-Z30BR or the MIC-7602-Z30WR?
Our take: The MIC-7522-Z30BR is the stronger choice when maximum frame rate is a project requirement, as its 60fps at 1080p provides a concrete advantage over the MIC-7602-Z30WR's 30fps ceiling for fast-motion capture scenarios. Conversely, the MIC-7602-Z30WR is the stronger choice for analytics-intensive deployments: it ships with IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy versus the 7522's standard IVA, and its Inteox OS supports third-party analytics app installation — a capability not documented in the 7522 spec sheet. The 7602 also explicitly lists ONVIF Profile M, enabling metadata streaming. All other key specs — sensor size, minimum illumination (0.0047 Lux color), lens range (6.6–198mm 30x), IP67/IK10 ratings, operating temperature (-40°C to +65°C), and PoE (802.3af) — are identical. Housing color (black vs. white) is the only remaining differentiator. Select the 7522 for high-frame-rate needs; select the 7602 for advanced edge analytics or open-platform extensibility.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Bosch MIC-7522-Z30BR | Bosch MIC-7602-Z30WR |
|---|---|---|
| Resolution | 2MP (1920 x 1080) | 2MP |
| Image Sensor | 1/2" CMOS | 1/2" CMOS |
| Max Frame Rate | 60fps @ 1080p | 30fps @ 1080p |
| Lens / Focal Length | 30x motorized; 6.6–198mm | 30x motorized; 6.6–198mm |
| Min. Illumination (Color) | 0.0047 Lux | 0.0047 Lux |
| Min. Illumination (B/W) | 0.0013 Lux | 0.0013 Lux |
| IR Illumination | 940nm invisible IR, Day/Night auto-switching | 940nm invisible IR, Day/Night auto-switching |
| Wide Dynamic Range | 120dB | 120dB |
| Video Compression | H.265, H.264, MJPEG | H.265, H.264, MJPEG |
| IP Rating | IP67 | IP67 |
| Impact / Vandal Rating | IK10 | IK10 |
| Operating Temperature | -40°C to +65°C (-40°F to +149°F) | -40°C to +65°C (-40°F to +149°F) |
| Power Input | PoE (802.3af) | PoE (802.3af) |
| ONVIF | Yes | Yes; Profile M |
| Edge Storage | microSD/SDHC/SDXC | microSD/SDHC/SDXC |
| Audio | Built-in audio input | Built-in audio input |
| Video Analytics | Intelligent Video Analytics, People Counting | IVA Pro Buildings, IVA Pro Perimeter, IVA Pro Privacy, People Counting |
| Housing Color | Black | White |
| Weight | 8.7 kg (19.2 lb) | — |
| NDAA Compliant | Yes | Yes |
| Multi-Streaming | 3 streams | 3 streams |
| Warranty | Manufacturer Warranty | Manufacturer Warranty |
Frequently Asked Questions
Which should you choose: the MIC-7522-Z30BR or the MIC-7602-Z30WR?
The MIC-7522-Z30BR is the stronger choice when maximum frame rate is a project requirement, as its 60fps at 1080p provides a concrete advantage over the MIC-7602-Z30WR's 30fps ceiling for fast-motion capture scenarios. Conversely, the MIC-7602-Z30WR is the stronger choice for analytics-intensive deployments: it ships with IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy versus the 7522's standard IVA, and its Inteox OS supports third-party analytics app installation — a capability not documented in the 7522 spec sheet. The 7602 also explicitly lists ONVIF Profile M, enabling metadata streaming. All other key specs — sensor size, minimum illumination (0.0047 Lux color), lens range (6.6–198mm 30x), IP67/IK10 ratings, operating temperature (-40°C to +65°C), and PoE (802.3af) — are identical. Housing color (black vs. white) is the only remaining differentiator. Select the 7522 for high-frame-rate needs; select the 7602 for advanced edge analytics or open-platform extensibility.
Is the MIC-7522-Z30BR or MIC-7602-Z30WR better for low-light performance?
Based on the provided specifications, both cameras are identical in low-light performance. Each uses a 1/2" CMOS sensor with a minimum illumination of 0.0047 Lux in color and 0.0013 Lux in black-and-white, and both use 940nm invisible IR with automatic day/night switching. Neither has a documented advantage over the other in this category.
Can both cameras run advanced video analytics at the edge?
They differ here. The MIC-7602-Z30WR (Inteox platform) includes IVA Pro Buildings, IVA Pro Perimeter, and IVA Pro Privacy, and supports third-party analytics app installation via its open OS. The MIC-7522-Z30BR (Starlight platform) lists Intelligent Video Analytics and People Counting, but does not document support for IVA Pro modules or third-party app installation based on the provided specs.
Which camera is better suited for capturing fast-moving subjects?
The MIC-7522-Z30BR supports up to 60fps at 1080p, compared to the MIC-7602-Z30WR's maximum of 30fps at 1080p. For applications involving fast motion — such as vehicle tracking, sports venues, or industrial conveyor monitoring — the 7522's higher frame rate provides smoother video and reduces motion blur compared to the 7602.
