ACTi Z714 vs ACTi Z810: Specification Comparison
Both the ACTi Z714 and ACTi Z810 are 8MP outdoor dome cameras sharing the same resolution class, IP67/IK10 environmental ratings, and 802.3af PoE power input. The core differentiator is lens architecture: the Z714 is a fixed mini dome with a 2.8mm wide-angle lens, while the Z810 is a varifocal zoom dome with a 2.8–12mm motorized lens offering 4.3x optical zoom. Installers and IT buyers choosing between them are trading off installation footprint and simplicity against post-mount focal flexibility and documented VMS ecosystem breadth.
In This Guide
How do the imaging specs compare?
Both cameras deliver 8MP resolution at up to 30 fps with H.265 and H.264 compression, WDR, and IR night vision. The Z714 uses a fixed 2.8mm / F2.0 lens producing a 99° horizontal field of view and is specified at 1440p @ 30 fps. The Z810 uses a varifocal 2.8–12mm lens (4.3x zoom range); its maximum resolution frame rate is listed as 30 fps, but no specific output resolution label such as 1440p is provided in the supplied specs.
Lens flexibility is the decisive imaging delta. The Z714's fixed 2.8mm covers wide-area scenes without any post-install adjustment. The Z810's 2.8–12mm varifocal allows the installer to dial in field of view from wide (approximately matching the Z714 at the short end) to telephoto-style narrow coverage—without repositioning the camera. Minimum illumination figures, IR range in meters, and sensor size are not specified for either model in the provided data.
What about installation and environment?
Both cameras carry identical environmental ratings: IP67 dust-tight and water-immersion protection, and IK10 vandal resistance. Both are powered by PoE 802.3af, allowing single-cable deployment on existing 802.3af-capable switches. The Z810 specifies an operating temperature range of -40°C to 60°C; no operating temperature range is listed in the provided specs for the Z714.
Form factor diverges meaningfully. The Z714 is a mini dome, suited to low-profile or space-constrained ceiling mounts. The Z810 is a standard dome with documented ceiling and wall mount compatibility. Neither camera's physical dimensions nor weight are provided in the supplied specifications.
Which fits your VMS and analytics better?
Both cameras support ONVIF Profile S/T, covering the baseline VMS interoperability most enterprise and SMB platforms require. The Z810 additionally lists explicit compatibility with Milestone XProtect, Genetec Security Center, and AXIS Camera Station in its supplied specs; no equivalent named-VMS compatibility list is provided for the Z714 beyond ONVIF Profile S/T.
Both models include a built-in microphone and a MicroSD card slot for local edge storage. No edge analytics capabilities, maximum MicroSD card capacity, or specific audio encoding formats are stated in the provided specifications for either model.
Which should you choose: the Z714 or the Z810?
Our take: The Z810 is the stronger choice when field of view must be confirmed or adjusted after mounting, when a wide operating temperature range down to -40°C is required, or when the project specifies Milestone XProtect, Genetec Security Center, or AXIS Camera Station as the VMS. Its 2.8–12mm varifocal lens (4.3x zoom) eliminates the need to reposition the camera to achieve the correct framing, a significant labor saving on difficult mounts. The Z714 is the appropriate choice for installations demanding the smallest possible dome footprint—a mini dome profile—where the scene is well-defined and a fixed 99° horizontal field of view at 2.8mm is sufficient. Both cameras are identical on resolution (8MP / 30 fps), compression (H.265 / H.264), power (802.3af PoE), environmental ratings (IP67 / IK10), audio (built-in mic), and edge storage (MicroSD). The operating temperature floor for the Z714 is not stated in the provided specs and should be confirmed before specifying it for extreme-cold sites.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | ACTi Z714 | ACTi Z810 |
|---|---|---|
| Resolution | 8 MP | 8 MP |
| Max Frame Rate | 1440p @ 30 fps | 30 fps (output resolution label not specified) |
| Lens / Focal Length | Fixed 2.8 mm, F2.0 | Varifocal 2.8–12 mm (4.3x zoom) |
| Horizontal Field of View | 99° | — |
| IR Night Vision | Yes | Yes |
| WDR | Yes | Yes |
| Video Compression | H.265; H.264 | H.265; H.264 |
| IP Rating | IP67 | IP67 |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | — | -40°C to 60°C |
| Power Input | PoE 802.3af | PoE 802.3af |
| Form Factor | Mini Dome | Dome |
| Mount Type | — | Ceiling; Wall |
| Edge Storage | MicroSD | MicroSD |
| Audio | Built-in mic | Built-in microphone |
| ONVIF | Profile S/T | Profile S/T |
| Named VMS Compatibility | — | Milestone XProtect; Genetec Security Center; AXIS Camera Station |
| MPN | Z714 | Z810 |
Frequently Asked Questions
Which should you choose: the Z714 or the Z810?
The Z810 is the stronger choice when field of view must be confirmed or adjusted after mounting, when a wide operating temperature range down to -40°C is required, or when the project specifies Milestone XProtect, Genetec Security Center, or AXIS Camera Station as the VMS. Its 2.8–12mm varifocal lens (4.3x zoom) eliminates the need to reposition the camera to achieve the correct framing, a significant labor saving on difficult mounts. The Z714 is the appropriate choice for installations demanding the smallest possible dome footprint—a mini dome profile—where the scene is well-defined and a fixed 99° horizontal field of view at 2.8mm is sufficient. Both cameras are identical on resolution (8MP / 30 fps), compression (H.265 / H.264), power (802.3af PoE), environmental ratings (IP67 / IK10), audio (built-in mic), and edge storage (MicroSD). The operating temperature floor for the Z714 is not stated in the provided specs and should be confirmed before specifying it for extreme-cold sites.
Is the Z714 or Z810 better for low light?
Neither camera's minimum illumination figure nor IR range in meters is provided in the supplied specifications. Both models include IR night vision and WDR, so a direct low-light comparison cannot be made from the available data. Consult the full ACTi datasheets for minimum lux values before specifying either for critical low-light applications.
Can I adjust the Z714's field of view after installation?
No. The Z714 uses a fixed 2.8mm / F2.0 lens with a stated 99° horizontal field of view. If the scene coverage needs to change after mounting, the camera must be physically repositioned. The Z810's varifocal 2.8–12mm lens allows focal length adjustment post-installation without moving the camera.
Do both cameras work with Genetec Security Center?
The Z810's provided specifications explicitly list Genetec Security Center as a compatible VMS alongside Milestone XProtect and AXIS Camera Station. The Z714's provided specifications list ONVIF Profile S/T only; Genetec compatibility is not confirmed in the supplied data. Both cameras' ONVIF Profile S/T support provides a baseline integration path, but named Genetec certification for the Z714 should be verified directly with ACTi.
