ACTi A92 vs Geovision MDR1200-0100: Specification Comparison
The ACTi A92 and Geovision MDR1200-0100 are both compact IP mini dome cameras designed for indoor and light-duty outdoor deployment, powered via PoE and mounted to ceiling or wall surfaces. The A92 is rated at 3 MP with Advanced WDR and dual H.264/H.265 compression, while the MDR1200-0100 delivers 1.3 MP over H.264 only. Though separated by a full resolution tier, both target the same fixed-dome, ONVIF-integrated installation category, making them a legitimate cross-shop for budget-conscious versus image-quality-driven procurement decisions.
In This Guide
How do the imaging specs compare?
The ACTi A92 captures at 3 MP, providing roughly 2.3× the pixel count of the Geovision MDR1200-0100's 1.3 MP sensor. This translates directly into greater detail density for license plate reads, facial recognition at distance, and digital zoom headroom in post-incident review. The A92 also specifies Advanced WDR, meaning it is engineered to handle high-contrast scenes—backlit entryways, glass facades, and mixed indoor/outdoor lighting transitions—without blowing out highlights or crushing shadows. The MDR1200-0100's provided specs do not list any WDR capability.
Both cameras are classified as Day/Night or equivalent fixed-lens domes, but the A92 explicitly carries a Day/Night designation suggesting an IR-cut filter mechanism for low-light switching. The MDR1200-0100 specifies a fixed 4.05 mm lens, giving installers a concrete field-of-view planning figure. The A92's lens specification is not present in the provided data. Neither camera's minimum illumination figure, IR range, or sensor size is provided in the supplied specs.
What about installation and environment?
Both units mount to ceiling or wall surfaces and draw power over Ethernet, eliminating separate power runs. The Geovision MDR1200-0100 specifies 802.3af PoE at a 13 W maximum, which is compatible with virtually any managed or unmanaged PoE switch without requiring higher-power 802.3at (PoE+) ports or injectors. The ACTi A92 lists PoE as its power source but does not specify the PoE standard (802.3af vs. 802.3at) or wattage draw in the provided data.
IP/IK environmental ratings, operating temperature ranges, and enclosure ingress protection class are not provided for either model in the supplied specifications. Installers should obtain the full datasheet for each unit before specifying either for outdoor or harsh-environment applications. The A92's product name includes 'Outdoor,' suggesting weather resistance, but no IP rating is confirmed in the provided specs.
Which fits your VMS and analytics better?
The ACTi A92 is listed as ONVIF Profile S compliant, a specific conformance level that guarantees interoperability for live streaming, PTZ control stubs, and relay I/O across certified VMS platforms including Milestone and Genetec. The Geovision MDR1200-0100 lists ONVIF compliance without specifying a Profile level (S, G, T, or M), which may require validation on the target VMS before deployment. Both cameras use an RJ-45 Ethernet connector; the MDR1200-0100 explicitly calls this out while the A92's connector type is implied by the PoE/Ethernet spec.
The A92 supports both H.264 and H.265 compression, with H.265 offering meaningful bitrate reductions—typically 40–50% over H.264 at equivalent quality—relevant to multi-camera storage budgets. The MDR1200-0100 is limited to H.264. Edge analytics, audio input/output, onboard SD card storage, and alarm I/O are not specified for either model in the provided data and should be confirmed via manufacturer datasheets prior to specification.
Which should you choose: the A92 or the MDR1200-0100?
Our take: The A92 is the stronger choice when image detail, WDR performance, and storage efficiency are primary requirements. It delivers 3 MP versus the MDR1200-0100's 1.3 MP—a 2.3× pixel advantage that materially improves evidentiary quality for facial and plate capture. Its Advanced WDR addresses high-contrast scenes that the MDR1200-0100's spec sheet does not claim to handle. H.265 support on the A92 can reduce per-camera storage consumption by roughly 40–50% compared to the MDR1200-0100's H.264-only stream, a significant operational cost delta across large deployments. ONVIF Profile S on the A92 provides a defined interoperability guarantee absent from the MDR1200-0100's unqualified ONVIF claim. The MDR1200-0100 is better positioned where switch infrastructure is limited to 802.3af 13 W budgets and where 1.3 MP resolution is sufficient—its PoE class ceiling is explicitly confirmed, the A92's is not.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | ACTi A92 | Geovision MDR1200-0100 |
|---|---|---|
| Resolution | 3 MP | 1.3 MP |
| Form Factor | Mini Dome | Mini Dome |
| Lens / Focal Length | — | 4.05 mm fixed |
| PTZ | Fixed (no pan/tilt/zoom) | Fixed (no pan/tilt/zoom) |
| Day/Night | Yes (Day/Night) | — |
| WDR | Advanced WDR | — |
| Video Compression | H.264; H.265 | H.264 |
| ONVIF | Profile S | Yes (profile not specified) |
| Power / PoE | PoE (standard not specified) | 802.3af, 13 W max |
| Connectivity | Ethernet (RJ-45 implied) | Ethernet, RJ-45 |
| Mount Type | Ceiling; Wall | Ceiling; Wall |
Frequently Asked Questions
Which should you choose: the A92 or the MDR1200-0100?
The A92 is the stronger choice when image detail, WDR performance, and storage efficiency are primary requirements. It delivers 3 MP versus the MDR1200-0100's 1.3 MP—a 2.3× pixel advantage that materially improves evidentiary quality for facial and plate capture. Its Advanced WDR addresses high-contrast scenes that the MDR1200-0100's spec sheet does not claim to handle. H.265 support on the A92 can reduce per-camera storage consumption by roughly 40–50% compared to the MDR1200-0100's H.264-only stream, a significant operational cost delta across large deployments. ONVIF Profile S on the A92 provides a defined interoperability guarantee absent from the MDR1200-0100's unqualified ONVIF claim. The MDR1200-0100 is better positioned where switch infrastructure is limited to 802.3af 13 W budgets and where 1.3 MP resolution is sufficient—its PoE class ceiling is explicitly confirmed, the A92's is not.
Is the A92 or MDR1200-0100 better for low-light performance?
The A92 carries an explicit Day/Night designation, indicating an IR-cut filter for low-light switching. The MDR1200-0100 does not specify Day/Night or IR capability in the provided specs. Neither camera's minimum illumination value is listed in the supplied data, so a full datasheet review is required before specifying either for low-light or zero-lux applications.
Will both cameras work on a basic 802.3af PoE switch?
The Geovision MDR1200-0100 explicitly specifies 802.3af at 13 W maximum, confirming compatibility with standard PoE switches. The ACTi A92 lists PoE as its power source but does not specify the standard or wattage in the provided specs—confirm with ACTi's datasheet before deploying on 802.3af-only infrastructure.
Which camera integrates more reliably with third-party VMS platforms like Milestone or Genetec?
The A92 specifies ONVIF Profile S, a defined conformance level that VMS vendors test against for guaranteed interoperability. The MDR1200-0100 lists ONVIF compliance without a Profile designation, which may require additional validation on your target VMS. For the lowest integration risk on certified platforms, the A92's Profile S claim provides a stronger foundation.
