Geovision 84-MDR1200-0100 1.3MP Mini Dome Camera
Overview
The Geovision 84-MDR1200-0100 is a 1.3MP fixed mini dome engineered for cost-conscious deployments across retail floors, office corridors, and public spaces where discreet ceiling or wall mounting reduces visual clutter without sacrificing network integration. The compact form factor and 4.05mm fixed lens deliver baseline surveillance footage while H.264 compression keeps bandwidth and storage consumption manageable on 24/7 recording — a critical factor when scaling across multiple locations. Weather-resistant sealing suits temperature-stable interiors and semi-protected exterior overhangs; this is not a full outdoor-rated unit, so skip it if you need IP67 submersion rating or extended IR range.
Compatibility
The 84-MDR1200-0100 integrates with any ONVIF-compliant NVR or VMS platform supporting H.264 streams, including Geovision's own GV-System, Milestone Xprotect, Axis Camera Station, and generic ONVIF recorders. Network connection uses standard RJ-45 Ethernet (IPCAM category). The camera draws under 13W via standard 802.3af PoE — meaning it operates on entry-level PoE switches without special power injection or injectors. This low wattage matters when you're consolidating power across a mixed-vendor infrastructure where budget switches lack the amperage budget for high-power cameras.
Installation Notes
Mount to ceiling or wall using the integrated bracket; flush mounting reduces vibration and improves image stability in high-traffic areas. Position the fixed 4.05mm lens during installation — the non-varifocal design means you cannot adjust zoom remotely or adjust focus after commissioning. Keep cable runs under 100 meters for standard PoE; longer runs require intermediate power injection or PoE extenders. Ensure the mounting surface can support the camera's weight and minor adjustment torque. Weather-resistant sealing is rated for splash exposure (restrooms, kitchens) but not heavy rain or extended outdoor exposure.
What's in the Box
- Geovision 84-MDR1200-0100 camera unit
- Mounting bracket
