Camden CI-PBU3 3-Button Industrial Control Station

Overview

The Camden CI-PBU3 is a three-button momentary-contact control station rated NEMA 1 for indoor industrial environments. It delivers 5A @ 30VDC switching capacity — sufficient for electric strikes, mag locks, and motor circuits in door automation and gate control systems. Surface-mount design fits door frames and wall surfaces in secured entries and loading-dock egress points without the complexity of panel-mount retrofit. UL listed and CSA certified for North American industrial deployment.

Compatibility

The CI-PBU3 integrates with access control systems, overhead door operators, and gate controls that accept hardwired 30VDC momentary switch closures for OPEN, CLOSE, and STOP commands. Compatible with electrified strikes, solenoid locks, and motor controllers designed for three-function push-button input. Works in retrofit applications where replacing existing button stations without rewiring the control logic is the goal. If your door or gate hardware expects hardwired relay contacts rather than networked inputs, this is the correct choice.

Installation Notes

Surface-mount anchoring to door frames or wall surfaces; verify structural bearing capacity before installation. Field wiring connects to the three momentary contacts via standard terminal blocks. NEMA 1 rating suits indoor factory and warehouse floors — do not expose to rain, washdown, or dust-heavy environments. If outdoor installation is required, specify the NEMA 4 variant instead. Standard hand tools and a multimeter for continuity testing are adequate for wiring verification.

What's in the Box

• 1x CI-PBU3 control station (assembled, NEMA 1 enclosure)
• Mounting hardware for surface installation
