Enclosure:
Enclosure with 2.5in speaker
Max sound pressure level:
>121 dB
Frequency response:
280 Hz - 12.5 kHz
Coverage pattern:
70° horizontal by 100° vertical (at 2 kHz)
Audio input/output:
Built-in microphone (can be disabled mechanically)
Built-in microphone specification:
50 Hz - 12 kHz
Digital signal processing:
Built-in and pre-configured
Amplifier description:
Built-in 7 W Class D amplifier
AXIS Audio Manager Edge:
Built in: – Content management for music and live/pre-recorded announcements. – Scheduling to decide when and where to play specific content. – Content prioritization to ensure urgent messages interrupt the schedule.
AXIS Audio Manager Pro:
For larger and more advanced systems. Sold separately. See separate datasheet for specifications.
AXIS Audio Manager Center:
AXIS Audio Manager Center is a cloud service for remote access and management of multi-site systems.
Audio streaming:
One-way/two-way audio, mono
Audio encoding:
AAC LC, G.711, G.726, µ-law, WAV, MP3 (8-48 kHz)
Model:
i.MX 6ULL
RAM:
256 MB RAM, 512 MB Flash
Network protocols:
IPv4/v6, HTTP, HTTPS, SIP, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, TCP, UDP, IGMPv1/v2/v3, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface:
Open API (VAPIX, ACAP)
VoIP:
SIP (Cisco, Bria, Grandstream, Asterisk)
Intelligent audio:
Auto Speaker Test
Features:
Virtual inputs, External input Call: DTMF, State changes, AXIS Camera Application Platform (ACAP)
Event actions:
File upload: HTTP, network share and email Notification: email, HTTP and TCP Play audio clip Perform Auto Speaker Test Send SNMP trap Status LED
Built-in installation aids:
Test tone verification and identification
Functional monitoring:
Auto Speaker Test, Connection Verification, Logging
Edge security:
Signed firmware, brute force protection, OAuth 2.0
Network security:
IEEE 802.1X, TLS 1.2/1.3, X.509 PKI, Host firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM)
Casing:
Impact-resistant aluminum, IP66/IP67, NEMA 4X
Power Type:
PoE
Connectors:
RJ45, 4-pin 2.5mm terminal block
Reliability:
Designed for 24/7 operation.
Operating Temperature:
-40°C to 60°C
Storage conditions:
-40°C to 65°C, 10-100% RH
Approvals:
EMC EN 55032, EN 50121-4, IEC 62236-4, FCC Part 15B, RCM, KC
Dimensions:
Ø182 X 52 mm (7.2 x 2.1 in)
Weight:
1.3 kg (2.9 lb.)
Included accessories:
Installation Guide, Auth Key, Connector Guard, Cable shoe
Optional accessories:
AXIS T91B47 Pole Mount, AXIS T91F67 Pole Mount, Cable Gland M20x1.5, RJ45, Cable Gland A M20, AXIS Power over Ethernet Midspans, T94R01B Corner Bracket, T94P01B Corner Bracket, T94S01P Conduit Back Box For more accessories, see axis.com
Video management software:
AXIS Camera Station, AXIS Companion
Languages:
English, German, French, Spanish, Italian
Warranty:
5-year warranty
Housing Color:
White
