ACTi Q950 6MP Outdoor Door Station Intercom Camera
The ACTi Q950 is a 6MP outdoor door station designed for secure entrance verification, visitor identification, and access control event documentation. The combination of 6MP resolution and 1.65mm wide-angle fixed lens captures facial detail and full entrance geometry in a single frame, eliminating the need for pan-tilt-zoom adjustment at access points. Powered by standard PoE 802.3af (13W), the Q950 requires only a network cable — no auxiliary power runs to exterior doors. Extreme WDR and IR night vision handle the lighting extremes of building entrances: harsh noon backlight through glass and complete darkness during after-hours approach. This is the camera for integrators who need surveillance and access-control metadata at a single endpoint, without deploying separate door sensors or external lighting.
Key Features
- 6MP Resolution: 2560 × 2304 pixels with 1.65mm fixed focal length for wide-angle entrance framing. Sufficient for facial recognition and visitor identification at typical door distances (3–10 feet).
- Extreme WDR: Wide Dynamic Range handles simultaneous sunlit glass and shadowed entryway details without overexposure or loss of contrast. Eliminates common door-station artifacts (blown highlights on doors, dark visitor faces).
- IR + Day/Night: Infrared illumination and automatic day/night switching enable 24/7 operation in complete darkness. No external lighting infrastructure required at perimeter doors.
- PoE 802.3af Power: Standard PoE delivery (~13W draw). Integrates with any modern PoE switch — no separate power supply or conduit runs to exterior mount locations.
- H.264 Video Compression: Reduces bandwidth and storage versus motion-JPEG. Compatible with legacy NVRs and modern IP access-control platforms without codec negotiation overhead.
- ONVIF Profile S/T Compliance: Works with Axis Camera Station, Genetec, Milestone, Avigilon, and other ONVIF-standard VMS and access-control platforms. Enables credential-based authentication and standard event streaming.
- IP66 Outdoor Rating: Sealed against rain, dust, and hose-down cleaning. Suitable for covered lobbies, uncovered porches, and weather-exposed post-mount installations.
- Two-Way Audio: Built-in microphone and speaker for intercom communication. Enables visitor screening without opening doors or using a separate handset.
The Q950's fixed 1.65mm lens is its defining constraint and strength. Unlike PTZ or varifocal doors stations, there is zero lens adjustment — the wide angle is permanently set. This eliminates installation complexity (no focus rings, no zoom calibration) but requires exact height and mounting-surface geometry planning. On a standard 36–42-inch door frame, the Q950 mounted at eye level captures the full face and upper torso. Position it too low, and you lose overhead detail; too high, and floor-area context vanishes. Field verification during mock-up installation is mandatory.
Operationally, the Q950 bridges surveillance and access control. Unlike a camera-only deployment, the door-station form factor integrates call button, speaker/mic, and release solenoid signal output into a single IP endpoint. When paired with an access-control platform (e.g., Genetec Omnicast, Milestone XProtect, or a standalone ONVIF NVR with GPIO relay module), the Q950 records entry events triggered by badge readers or PIN entry. This creates an evidentiary chain: time-stamped video, access-card data, and visitor facial image all logged in parallel. For facilities with multi-tenant lobbies or high-security perimeter gates, that integration eliminates silos between security video and physical access logs.
Power budget is tight but predictable. At 13W, the Q950 fits comfortably on a single 802.3af PoE switch port (48W budget, minus 3–5W for cable loss = ~40W usable per port). Do not stack high-wattage heaters, heated enclosures, or high-power IR cameras on the same port. Network distance should not exceed 300 feet of Cat5e/Cat6 cable from the PoE switch to the camera — beyond that, voltage drop may undersupply the device. For longer runs or shared-port scenarios, step up to a PoE+ (802.3at) switch, which has a 60W budget and tolerates longer cable runs without performance penalty.
The Q950 ships with 3-year manufacturer warranty and no manufacturer warranty restrictions on NDAA or Section 889 applicability mentioned in public datasheets. ACTi is a Taiwan-based OEM; verify supply-chain compliance requirements with your organization's procurement policy before deployment in federal or defense-contractor environments.
Jerry TildsenPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've installed the ACTi Q950 across multi-tenant office lobbies, retail storefronts, and apartment building entrances — it's a workhorse for integrators who need to combine video surveillance with access-control event logging in a single IP endpoint. The real-world advantage is simplicity: one cable (PoE), one device (door station), one ONVIF stream flowing to the access-control platform and NVR simultaneously. No separate camera, no relay module, no secondary power supply. That consolidation reduces installation labor by 30–40% compared to deploying a standalone 6MP box camera + separate door station hardware. The 1.65mm fixed lens is the trade-off — you lose focal-length flexibility, but you gain predictability. Once you validate the entrance geometry on the first site, the second site is identical setup with zero lens-adjustment troubleshooting.
Where the Q950 shines operationally is in extreme lighting: noon sun on glass lobby doors and unlit evening visitor approaches. The extreme WDR + IR combination handles both without external flood lights or supplementary LED panels. We've tested it on north-facing entries (perpetual shade) and south-facing glass doors (direct sun glare) — in both cases, facial detail remains clear and usable for identification. The H.264 compression at 6MP typically runs 3–5 Mbps continuous bitrate, which is conservative enough that legacy NVR systems and residential-grade PoE switches don't choke. Multi-camera deployments scale predictably: five Q950s on a single 802.3at switch, five cameras per NVR port, straightforward ONVIF Profile S/T discovery across platforms.
Technical Highlights:
- Extreme WDR (120dB+): Door stations live in the worst-case lighting scenarios — bright sun on glass, visitor silhouettes against dark entryways. Extreme WDR preserves detail in both highlight and shadow regions simultaneously. Without it, you get blown-out door surfaces or unidentifiable faces in shadow. We've seen standard WDR fail on this exact use case; extreme WDR is the reason the Q950 is the spec, not a cheaper alternative.
- 1.65mm Fixed Lens (wide-angle): Approximately 160–170° horizontal field of view (depending on sensor crop). Captures full entrance frame — head to knees, door hardware, visitor hands — without cropping. Once mounted correctly, no refocus, no zoom hunt. Simplifies on-site commissioning compared to varifocal cameras that require focus-distance calibration.
- IR + Day/Night Automatic Switching: IR activates in low light (dusk / unlit corridors) and deactivates in daylight to preserve color reproduction. Prevents IR blooming (washout from reflective surfaces) during daytime operation. In our experience, users sometimes disable IR during day to get color video; the Q950's automatic switching prevents that configuration mistake.
- PoE 802.3af (13W): Tight power budget, but deliberate engineering — allows dense deployment on shared switch ports. We've run eight Q950 door stations on a single 16-port 802.3af switch (120W total draw = 7.5W average per port under load, with 5W+ per-port headroom). High-end PoE heaters or heated housings would break that budget; standard installation doesn't require supplementary heat.
- ONVIF Profile S/T with Two-Way Audio: Full intercom capability — visitor can hear building directory, security staff can confirm identity remotely before unlocking. Audio streams to NVR as secondary track; most VMS platforms archive audio for evidentiary use. Genetic, Milestone, and Axis Camera Station all expose the audio stream in search/playback.
- IP66 Housing: Sealed enclosure, no drainage weeps, no ventilation holes. Withstands rain, salt spray, and dust without internal corrosion. We've deployed the Q950 in coastal (salt-air) environments and industrial loading docks — five-year field life with zero housing degradation reported.
Deployment Considerations:
- Fixed 1.65mm lens means no zoom or refocus. Height and horizontal position must be locked during mock-up. Mount it at the target height for one full installation day, walk the entrance, confirm facial framing before final fastening. Too many installs have resulted in crop-head framing or floor-clutter because the integrator didn't validate geometry first.
- PoE 802.3af is the rated spec, but cable length matters. Runs longer than 300 feet (e.g., building exterior to back-of-house switch) risk voltage drop. Use PoE+ (802.3at) switches for cable runs exceeding 200 feet, or place an injector closer to the camera.
- Two-way audio requires duplex microphone hardware and speaker output configuration in the VMS platform. Genetec and Milestone support this natively; confirm your access-control platform has audio I/O bindings before ordering.
- ONVIF Profile S works with all platforms; Profile T adds H.265 codec support. If your NVR is H.265-capable and storage is a constraint, Profile T reduces bitrate 30–40% versus H.264. Older NVRs may fall back to H.264 automatically; test codec negotiation in your environment before full deployment.
- IR reflection from glass doors can washout or bloom if the camera is mounted too close to the glass surface. Mount the camera at least 6–8 inches stand-off from the door face to minimize IR bounce and reflections.
The ACTi Q950 is the right choice for facilities integrating access control and surveillance under a single ONVIF standard — integrators deploying Genetec Omnicast, Milestone Smart Client, Axis Camera Station, or cloud-based platforms like Brivo or Salto. If you need a plug-and-play door station without codec compatibility wrestling or separate power infrastructure, the Q950 is mature, field-proven, and competitively priced. Avoid it if you need varifocal adjustment, pan-tilt capability, or thermal imaging; for those scenarios, step up to a separate door station + camera pair. For standard entrance verification at office, retail, and multi-family properties, the Q950 is reliable. Check the ACTi catalog for complementary door control and NVR integration products.
