Sensor Type:
1/2.8" (2 MP) progressive scan CMOS
Minimum Illumination:
Color: 0.028 lux @ (f/2.0, AGC on)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Auto-Iris:
No
Day /Night:
IR cut filter
Digital Noise Reduction:
3D DNR
Features:
Digital
Angle Adjustment (Bracket:
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
Focal Length:
2.8 mm, 4 mm, 6 mm
Aperture:
f/2.0
Focus:
No
Field of View:
6 mm, horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
Lens Mount:
M12
IR Distance:
Up to 100 ft (30 m)
Wavelength:
850 nm
Video Compression:
H.265+/H.265/H.264+/H.264/MJPEG
H.265 Type:
Main profile
H.265:
Main stream
Video Bit Rate:
32 Kbps to 8 Mbps
Region of Interest:
One fixed region for main stream and sub-stream
Max Resolution:
1920 × 1080
Main Stream:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
30 fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:
BLC, 3D DNR
Image Setting:
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch:
Auto, scheduled
Alarm Trigger:
Motion detection, video tampering alarm, illegal login
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View:
Up to 6 channels
User/Host:
32 users (3 role levels)
Client:
iVMS-4200, Hik-Connect
Web Browser:
IE 8+, Chrome 31 to 44, Firefox 30.0 to 51, Safari 8.0+
Communication Interface:
1-port RJ-45 10M/100M self-adaptive Ethernet port
Operating Temperature:
-30°C to 50°C
Power Type:
12 VDC, 5.5 mm coaxial power plug; PoE (802.3af, class 3)
Power Consumption and Current:
5 W (12 VDC) / 6.5 W (PoE)
Protection Level:
IP67
Material:
Metal
Dimensions:
Ø 4.3" x 3.7" (Ø 110 mm x 93.2 mm)
Weight:
0.80 lbs (360 g)
Housing Color:
White
