Frame Rate:
30fps
Sensor Type:
1/2.8" Progressive Scan CMOS
Min. Illumination:
0.0005 Lux (B/W, F1.2, AGC ON)
Shutter Speed:
1 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120 dB
Angle Adjustment:
Pan: 0 to 360°, tilt: 0 to 100°, rotation: 0 to 360°
DNR:
3D DNR
Day & Night:
IR Cut Filter
Lens Type:
4.7 to 94 mm
Auto-Iris:
DC drive
Aperture:
F1.5 to F3.0
Field of View:
55° to 3° horizontal, 62° to 3.6° diagonal
Lens Mount:
Integrated
IR Distance:
Up to 120 m
Wavelength:
850 nm
Max. Resolution:
1920 × 1080
Main Stream:
1920×1080 @ 60fps
Sub Stream:
25fps @ 704×576 (50Hz) / 30fps @ 704×480 (60Hz)
Third Stream:
25fps @ 50Hz, 30fps @ 60Hz (1920×1080)
Video Compression:
H.265/H.264/MJPEG
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Video Bit Rate:
32 Kbps to 16 Mbps
SVC:
H.264 and H.265 encoding
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64 Kbps (G.711) / 16 Kbps (G.722.1) / 32-192 Kbps (MP2
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Region Of Interest:
4 fixed regions + dynamic tracking
Statistics:
Counting
Exception Detection:
Scene change, defocus, audio detection
Face Detection:
Yes
Perimeter Protection:
Line crossing, intrusion, region detection, baggage alert
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS
Image Setting:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping:
Yes
Day/Night Switch:
Day/Night/Auto/Schedule/Alarm
Picture Overlay:
Logo overlay, 128×128 BMP
Network Storage:
microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View:
Up to 20 channels
User/Host:
32 users, 3 levels
Client:
iVMS-4200, Hik-Connect
Web Browser:
IE 8+, Chrome 41.0-44, Mozilla Firefox 30.0-51, Safari 8.0+
Alarm Trigger:
Motion detection, tampering, disconnection alerts
Communication Interface:
1x RJ45 10/100M Ethernet, 1x RS-485
Audio Support:
1 input (line in/mic in, 3.5 mm), 1 output (3.5 mm), mono sound
Alarm:
1 input, 1 output (max. 24 VDC, 1A or 110 VAC, 500 mA)
Video Outputs:
1Vp-p composite output (75 Ω/BNC)
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
H.264:
Main stream supports
H.265:
Main stream supports
General Function:
One-key reset, anti-flicker, three streams, heartbeat, mirror. password protection, privacy mask, watermark, IP address filter
Reset:
Yes
Startup And Operating Conditions:
-30 to 60°C, -40 to 60°C (-H), 95% RH
Power Type:
12 VDC / PoE (802.3at)
Power Consumption And Current:
12 VDC 1.3A / PoE+ 15W
Material:
Metal
Dimensions:
Camera: 348.4 × 114.2 ×111.7 mm (13.7" × 4.5" × 4.4"),With package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1")
Weight:
1300-2000 g
Heater:
-H: yes
Interface Protection:
IP67
Firmware Version:
5.5.80
Power Consumption and Current:
12 VDC 1.3A / PoE+ 15W
Housing Color:
White
