Frame Rate:
30fps
Sensor Type:
2.54cm (1/2.8inch) Progressive Scan CMOS
Min. Illumination:
0.005 Lux (Color), 0 Lux (IR)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Support
Day & Night:
IR Cut Filter
Digital Noise Reduction:
3D DNR
Wide Dynamic Range:
120dB
3-Axis Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Focal Length:
2.8 to 12 mm
Aperture:
F1.6
Field of View:
97° to 33° horizontal
Lens Mount:
Φ14
IR IR Range:
Up to 30 m
Wavelength:
850nm
Video Compression:
H.265+/H.265/H.264+/H.264/MJPEG
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
Video Bit Rate:
32 Kbps to 16 Mbps
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64Kbps G.711, 16Kbps G.722.1, 32-192Kbps MP2L2
Behavior Analysis:
Line crossing, intrusion, baggage, object removal
Face Detection:
Support
Region of Interest:
Support 1 fixed region for main stream and sub stream
Max. Resolution:
2048 × 1536
Main Stream:
25fps @ 50Hz, 30fps @ 60Hz
Sub Stream:
25-30fps, 640×360
Third Stream:
25-30fps, up to 1280×720
Image Enhancement:
BLC/3D DNR
Image Setting:
Rotate, saturation, brightness, contrast, sharpness
Day/Night Switch:
Auto/Schedule/Triggered by Alarm In
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger:
Motion detection, tampering, network, HDD, alarm I/O
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function:
One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View:
Up to 6 channels
User/Host:
Up to 32 users3 levels: Administrator, Operator and User
Client:
iVMS-4200, Hik-Connect, iVMS-5200
Web Browser:
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Audio Support:
1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA)
Video Outputs:
1Vp-p composite output (75 Ω/BNC)
On-board storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
SVC:
Support H.264 and H.265 encoding
Reset Button:
Support
Environment Noise Filtering:
Support
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHZ/48kHz
Operating Temperature:
30 to 60°C
Power Type:
12 VDC ± 25%, PoE (802.3af) Terminal block for DC input
Power Consumption and Current:
12 VDC 0.92A / PoE 802.3af 12.5W
Protection Level:
IP67, IK10, 2000V surge protection
Material:
Metal
Dimensions:
Φ 135.8 mm × 145.5 mm (Φ 5.35inch× 5.73inch)
Weight:
1060 g (2.34 lb)
Housing Color:
White
