Frame Rate:
30fps
Sensor Type:
1/2.8" Progressive Scan CMOS
Min. Illumination:
0.005 Lux (Color, F1.2, AGC ON)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Focus:
Auto
Field of View:
105°-35° horizontal, 56°-20° vertical
Aperture:
F1.4
Lens Mount:
Φ14
IR Distance:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
1920 × 1080
Main Stream:
50Hz: 50fps, 60Hz: 60fps (1920×1080, 1280×960, 1280×720)
Sub Stream:
25-30fps, 320-640×240-480
Third Stream:
30fps 1920×1080
Video Compression:
H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
Support H.264 and H.265 encoding
Region Of Interest (ROI:
Support 1 fixed region for main stream and sub stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHZ/48kHz
Audio Compression:
G722.1/G711/G726/MP2L2/PCM
Audio Bit Rate:
32 Kbps to 16 Mbps
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Chrome 57+, Firefox 52+, Safari 11+, IE8+
Alarm Trigger:
Motion, tampering, network, login, HDD, alarm I/O
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio Support:
1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA)
Video Outputs:
No
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Event:
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Face Detection:
Yes
Exception Detection:
Scene change detection
Firmware Version:
V5.5.80
Web Client Language:
32 languages
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30 to +60°C, 95% RH non-condensing
Power Type:
12 VDC ± 25%, PoE (802.3af),Terminal block for DC input
Power Consumption And Current:
12V 11W / PoE 12.5W
Camera Dimension:
Φ 135.8 mm × 145.5 mm (Φ 5.35" × 5.73")
Camera Weight:
1060 g (2.34 lb)
Protection:
IP66, IK10
Housing Color:
White
