Sensor Type:
1/2.8" Progressive Scan CMOS
Min. Illumination:
0.01 Lux (F1.2, AGC ON)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Focus:
Auto
Lens Type:
2.8 to 12 mm,Motorized
Field of View:
110°-31° horizontal, 58°-18° vertical
Aperture:
F1.6
Lens Mount:
Φ14
Aperture Type:
Fixed
IR Distance:
Up to 50 m
Wavelength:
850nm
Max. Resolution:
1920 × 1080
Main Stream:
30fps 1920×1080
Sub Stream:
25-30fps, 320-640px
Third Stream:
1920×1080 30fps
Video Compression:
H.265/H.264, H.265/H.264/MJPEG, H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Audio Compression:
G722.1/G.711/G726/MP2L2/PCM/MP3
Audio Bit Rate:
8-320 Kbps (MP3)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser:
Chrome 57.0+, Firefox 52.0+, Safari 11+, IE8+
Alarm Trigger:
Motion detection, tampering, network alerts
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by alarm in
Target Cropping:
No
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Video Outputs:
1Vp-p composite output(75Ω) (For adjustment only)
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, face detection
Linkage Method:
Trigger recording: SD card, network storage, email
Web Client Language:
32 languages
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30°C to +60°C, 95% humidity
Power Type:
12 VDC ± 25%, terminal block,PoE (802.3at, class 4)
Power Consumption And Current:
12 VDC 1.2A / PoE+ 18W max
Camera Dimension:
Φ 144.13 × 332.73 mm (Φ 5.7" × 13.1")
Camera Weight:
1740 g (3.8 lb)
Protection:
IP67
Housing Color:
White
