Middle Atlantic WR-24-32 24U 32-Inch Deep Rollout Rotating Rack
Overview
The Middle Atlantic WR-24-32 is a 24-rack-unit rollout rotating rack designed for equipment rooms and closets where front-and-rear access is constrained. At 32.88 inches deep with 26 inches of usable depth, the WR-24-32 accommodates deep servers, NVRs, and AV processing gear that would be difficult to service in a fixed-position frame. The rolling and rotating mechanism lets a single technician swing the entire loaded rack clear of the wall — practical for cable management, equipment swaps, or troubleshooting in tight telecom rooms and security head-end closets. The 750 lb UL-rated load capacity handles dense security and IT hardware without imposing strict per-shelf limits that force load redistribution. The black wrinkle powder coat finish is standard for equipment room builds where aesthetics are secondary to durability. TAA-compliant and US-made — relevant for federal, state, and government-adjacent deployments where procurement rules require domestic origin. The 10-32 rack rail threading is the commercial-grade standard, compatible with the full range of rackmount hardware used in network video recorder and IT deployments.
Compatibility
The WR-24-32 accepts any standard 19-inch EIA-310 rackmount equipment using 10-32 threaded rails. This covers Middle Atlantic's own Middle Atlantic accessory line — shelves, blanks, cable managers, and PDUs — as well as third-party 1U through 4U gear from security, networking, and AV product families. The 26-inch usable depth accommodates most 1U and 2U network switches, NVRs, and UPS units. Verify equipment depth against the 26-inch usable figure — deeper chassis (some high-density servers and 4-post configurations) may require depth measurement before ordering. The rotating base requires a minimum floor clearance arc; confirm the installation footprint allows the full swing path before positioning against adjacent walls or furniture.
Installation Notes
Product weight is 213.8 lbs unloaded; plan for two-person placement and use a pallet jack or equipment dolly during positioning. The unit ships at 244 lbs — factor freight class and liftgate requirements into delivery planning. Floor surface must support the combined rack and equipment load up to 750 lbs across the caster footprint. Confirm floor rating in raised-floor or older construction environments. Casters are pre-installed; no rail assembly is required before loading equipment.
