Middle Atlantic Swing Frame Rack 25 Space (43-3/4IN. ) 24IN. Depth - SFR-25-24

Middle Atlantic SFR-25-24 25U Swing Frame Wall Rack

Overview

The Middle Atlantic SFR-25-24 is a 25U swing-frame wall rack designed for equipment rooms, server closets, and AV/security head-end locations where floor space is constrained but rear-panel access to rack-mounted gear is non-negotiable. The swing-frame design lets the entire rail assembly pivot away from the wall, giving a technician unobstructed access to cable terminations, power connections, and rear-panel ports — without pulling equipment from the rack. At 24.2 inches deep and 43.81 inches of usable racking height, the SFR-25-24 accommodates full-depth 1U–4U equipment including NVRs, patch panels, UPS units, and access control servers up to a 100 lb aggregate load. The 14-gauge steel backpan and 11-gauge steel rackrails deliver a noticeably heavier construction than lighter swing frames, and the black powder-coat finish suits both finished telecom rooms and utility spaces. The open-back design allows rear cable runs and ventilation without requiring a dedicated cooling solution for most light-to-medium-density builds.

Compatibility

Fits any 19-inch EIA-standard rack-mount equipment — including network video recorders, PoE-managed network switches, access control panels, patch panels, and 1U–2U servers. The 25 RU capacity and 24-inch rail depth cover the majority of commercial-grade NVRs and appliances in the Middle Atlantic rack ecosystem. Pairs directly with standard Middle Atlantic rack accessories: blank panels, vented filler panels, horizontal cable managers, and brush-panel grommet strips, all of which mount to the 11-gauge rackrails without modification. The wall-mount footprint suits both stud-wall and concrete/masonry installations — verify your fastener selection against wall construction type and local code for the 100 lb rated load.

Installation Notes

Wall mounting requires locating studs or using appropriate masonry anchors rated for the combined weight of the SFR-25-24 and installed equipment — the 100 lb capacity is the equipment load limit, not the anchor rating. The open-back design requires that all cabling be managed before swinging the frame closed; plan cable slack and routing with the pivot arc in mind to avoid strain on rear-panel connections. Overall installed dimensions are 49.97 in H × 19.6 in W × 24.2 in D; confirm clearance for the full swing arc before wall positioning. Consult the rack accessories category for compatible horizontal cable managers and brush panels to keep swing-frame operation clean and repeatable.
