Model:
MD9582-H(2.8mm)
CPU:
Multimedia SoC (System-on-Chip)
Flash:
1B
RAM:
2B
Image Sensor:
1/2.7" Progressive CMOS
Max. Resolution:
2560x1920 (5MP)
Lens Type:
Fixed-focal
Focal Length:
MD9582-H(2.8mm) & MD9582-H(DMS)*: f = 2.8 mm
Aperture:
MD9582-H(2.8mm) & MD9582-H(DMS)*: F1.8
Iris Type:
Fixed Iris
Field of View:
MD9582-H(2.8mm) & MD9582-H(DMS)*: 102° (H)/ 76o(V)/ 129o(D)
Shutter Time:
1/5 sec. to 1/32,000 sec.
WDR Technology:
WDR Pro
Day/Night:
Yes; MD9582-H(DMS)*=night mode only.; *Optional
Removable IR-cut Filter:
Yes
IR Illuminators:
Built-in IR illuminators, effective up to 20 meters with Smart IR, IR LED x2;; *Optional MD9582-H(DMS): Built-in invisible 940nm IR illuminators, effective up to 2 meters, IR LED x2
Minimum Illumination:
MD9582-H(2.8mm): 0.0.9 lux @ F1.8 (Color); 0.01 lux @ F1.8 (B/W); 0 lux with IR illumination on
Pan Range:
± 30°
Tilt Range:
90°
Rotation Range:
± 180°
Pan/Tilt/Zoom Functionalities:
ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
Storage:
Seamless Recording to MicroSD/SDHC/SDXC card slot and recording to network-attached storage (NAS)
Video Compression:
H.265, H264, MJPEG
Maximum Frame Rate:
30 fps @ 2560x1920; 60 fps @ 1920x1080
Maximum Streams:
3 simultaneous streams (Up to 8 configurable profiles)
S/N Ratio:
MD9582-H(2.8mm) & MD9582-H(DMS)*: 55dB
Dynamic Range:
120 dB
Video Streaming:
Adjustable resolution, quality and bit rate, Smart Stream III
Image Settings:
General settings: video title and time stamp overlay, video orientation (flip, mirror, rotation), day/night settings; Illuminators: illuminators, anti-overexposure; Image settings: white balance, image adjustment
Audio Capability:
One-way audio
Audio Compression:
G.711,.726, MPEG-2 AAC-LC
Audio Interface:
Built-in microphone; External line input
Effective Range:
5 meters
Users:
Live viewing for up to 10 clients
Security:
Access list, Account block , Audit log, Configurable password strength protection, CSRF protection, Digest authentication, HTTPS , IEEE 802.1x, Secure boot, Session timeout, Signed firmware, Trend Micro IoT Security
Protocols:
802.1X, ARP, Bonjour, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
Interface:
10Base-T/100 BaseTX Ethernet (M12, Female, 4pin D-coded)
ONVIF:
Profile, S, T supported, specification available at www.onvif.org
Smart Motion Detection:
Five-window video motion detection, people detection, time filter
Smart VCA:
*Optional, please contact transportation@vivotek.com for further support.
VADP Package:
Trend Micro (3-year free trial), Deep Learning VCA (Smart Motion Detection, Smart VCA*),; DMS(Driver Mnagement System for MD9582-H(DMS)*.; * Optional
Event Trigger:
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy
Event Action:
Event notification via audio clip, camera link, digital output, email, HTTP, FTP/SFTP, NAS server, SD card, push notification and ONVIF events (DMS_driver_change, DMS_no_driver, DMS_object_near_mouth, DMS_object_near_near, DMS_distraction
Connectors:
M12 4pin D-coded, Female connector for 10/100Mbps Network/PoE connection; Audio input *1; Digital input *1; Digital output *1
LED Indicator:
System power and status indicator
Power Input:
IEEE 802.3af PoE Class 2
Power Consumption:
Max. 6 W/4.5 W (IR on/off)
Dimensions:
98 x 54 x 110.8 mm
Weight:
approx. 400 g
Certifications:
EMC: CE (EN 55032, EN 55024 Class B, EN 50121-4, EN 50121-3-2), FCC (FCC Part 15 Subpart B Class B), RCM (AS/NZS CISPR 32 Class B), VCCI (VCCI-CISPR 32 Class B);; Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471)
Operating Temperature:
Starting Temperature: -40°C ~ 70°C (-40°F ~ 158°F); Working Temperature (IR off): -40°C ~ 70°C (-40°F ~ 158°F) (IR off); -40°C ~ 65°C (-40°F ~ 149°F) (IR on)
Humidity:
98% RH (non-condensing)
Storage Temperature:
-40°C ~ 70°C (-40°F ~ 158°F)
Operating System:
Microsoft Windows 10/8/7; Mac 10.12 (Chrome only)
Web Browser:
Chrome 58.0 or above; Internet Explorer 10/11
Other Players:
VLC: 1.1.11 or above
Packing Contents:
Quick installationuide, alignment sticker, screwdriver, accessories bag
