Vivotek AW-IHU-0200 Industrial 60W UPoE Gigabit Switch

Vivotek AW-IHU-0200 Industrial 60W UPoE Gigabit Ethernet Switch

The Vivotek AW-IHU-0200 is a rugged industrial network switch engineered for demanding surveillance and security applications. With 60W Ultra Power over Ethernet (UPoE) capability and dual Gigabit connectivity, this switch delivers the power and performance required for high-consumption devices like PTZ cameras in harsh industrial environments. Built for extreme temperature ranges and comprehensive protocol support, the AW-IHU-0200 ensures reliable operation in mission-critical security deployments.

Key Features

• 60W UPoE Power Delivery: Single PoE output port supplies up to 56VDC at 60W maximum, enabling power-hungry industrial cameras and network devices
• Dual Gigabit Connectivity: One RJ45 Gigabit Ethernet port plus one SFP Gigabit Ethernet slot for flexible network expansion
• SFP Fiber Expansion: Support for optional industrial-grade SFP transceivers (0.5 km to 40 km range options) enables long-distance connectivity across large facilities
• Industrial-Grade Construction: Rugged metal housing with IP30 protection, DIN-rail and wall-mounting options for flexible deployment
• Extended Temperature Operation: Rated -40°C to 75°C operating range handles freezing and high-heat industrial environments
• PoE Auto-Detection: Intelligent detection and power delivery prevents over-current and short-circuit damage to connected devices
• Compact Design: Lightweight (0.14 kg) with minimal footprint (103.5 x 32 x 81.5 mm) for space-constrained installations

Technical Specifications

Network Performance: 2 Gbps backplane with Store-and-Forward transmission, 128 KB buffer memory, and support for 9 KB Jumbo Frames. Throughput rates of 1,488,000 pps at 1000Mbps ensure minimal latency for video streaming and real-time surveillance data.

Protocol Support: Full support for IEEE 802.3 standards (10-BASE-T, 100-BASE-TX, 1000-BASE-T), IEEE 802.3z (1000-BASE-X fiber), IEEE 802.3at PoE+, and IEEE 802.3x flow control. Auto-MDI/MDI-X and auto-negotiation simplify deployment with any standard Ethernet cabling (Cat. 5e minimum for Gigabit).

Power Management: Requires 50–56VDC input with 72W total power consumption. Supports external DIN-rail or wall-mount power supplies (optional NDR-75-48 or HLG-80H-54 available). Relay alarm outputs (1A @ 24VDC) enable integration with security monitoring systems.

Certifications & Compliance: CE, C-Tick, FCC, VCCI, LVD certified. Meets EN 55022/24, EN 55011, and EN 60068 environmental stability standards.

Applications

• Industrial IP video surveillance systems with high-power PTZ cameras
• Manufacturing and utility networks requiring extended temperature operation
• Multi-building campuses using fiber SFP links for backbone connectivity
• Oil, gas, and mining facilities requiring rugged, reliable network infrastructure
• Traffic monitoring and public safety systems in outdoor environments

Eden Phillips

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The AW-IHU-0200 bridges industrial networking and surveillance security with purpose-built reliability. Its 60W single-port UPoE output is ideal for PTZ and multi-sensor cameras that exceed standard PoE+ (30W) budgets, while the SFP slot provides scalable fiber expansion without requiring a second device. The -40°C to 75°C operating range is exceptional for outdoor and unheated facility deployments where commercial switches fail.

Store-and-forward switching with 128 KB buffering minimizes packet loss on congested networks, critical for synchronizing multiple camera streams. The compact metal chassis and DIN-rail support make integration into industrial control cabinets straightforward. For organizations consolidating network infrastructure in remote or extreme-environment locations, this switch reduces deployment complexity and long-term maintenance costs.
