APC by Schneider Electric ACAC76117 Relay

Overview

The APC by Schneider Electric ACAC76117 is a 24V relay module designed to interface remote fire and smoke sensors with environmental monitoring systems. It provides a dry contact relay output, enabling seamless integration into existing surveillance and building management infrastructures. This unit is specifically engineered for deployment in environments requiring proactive environmental hazard detection and reporting, such as data centers or critical infrastructure facilities where immediate alerts are paramount. The ACAC76117 model number ensures precise identification for procurement and installation.

Compatibility

This relay module is engineered for direct integration with APC's Uniflair environmental monitoring systems. It is intended to work with compatible remote fire and smoke sensors that provide a trigger signal. The dry contact output is designed to interface with standard alarm input panels or VMS systems that accept digital inputs for event notification. Specific compatibility details with third-party systems should be verified against the environmental monitoring system's input specifications.

Installation Notes

Requires a 24V power source for operation. The unit provides a dry contact relay output, meaning it does not supply voltage itself but rather closes or opens a circuit when activated. Installation involves connecting the sensor input, the 24V power supply, and the relay output terminals to the appropriate points on the environmental monitoring system or VMS. The dimensions are 7.7" W x 7.7" D x 3.6" H, requiring adequate space for mounting and wiring.
