Description

APC by Schneider Electric BVS480XDPDR DIN Rail Mount Switch Power Supply Battery Back Up 24V DC

Overview

The APC by Schneider Electric BVS480XDPDR is a 480W DIN rail mountable switch mode power supply designed for critical applications requiring stable 24V DC power. It provides 20A maximum output current and features battery backup functionality, ensuring continuous operation during power interruptions. This unit is engineered for industrial automation, control systems, and surveillance deployments where uptime is paramount. Its compact 40mm width conserves panel space, making it suitable for densely populated enclosures.

Compatibility

This power supply is designed to integrate with standard 24V DC systems. It is compatible with various industrial control panels, automation equipment, and network video recorders (NVRs) that operate within its 21.6-28.8V DC input range and require up to 20A of continuous power. The DIN rail mounting ensures broad compatibility with standard industrial mounting hardware.

Installation Notes

Mounting is via standard 35mm DIN rail. The unit requires a minimum operating temperature of -15°C and a maximum of 50°C. Ensure adequate ventilation, as the acoustic level is rated at 40 dB. Maximum input current is 20A, and the output overload operation allows for 60 seconds at 130% and 30 seconds at 145% of rated load, providing tolerance for transient demands.

What's in the Box

  • 1x APC by Schneider Electric BVS480XDPDR Power Supply
  • 1x User Manual
Expert Analysis
Specifications
Input Voltage: 24 V DC
Output Voltage: 24 V DC
Rated Power: 480 W
Battery Voltage: 24 V
Height: 129 mm
Width: 40 mm
Depth: 119 mm
Net Weight: 0.5 kg
Mounting Mode: DIN rail mount
Input Voltage Limits: 21.6...28.8 V
Maximum Input Current: 20 A
Output Overload Operation: 60 s at 130% and 30 s at 145%
Efficiency: 95 %
Maximum Output Current: 20 A
Product Certifications: CE, TÜV
Standards: UL 60950-1, IEC 62368-1, CSA-C22.2 No 62368-1-14, IEC 61010-1
Operating Temperature: -15…50 °C
Relative Humidity: 0…95 % non-condensing
Operating Altitude: 0...3000 m
Storage Temperature: -15…70 °C
Storage Relative Humidity: 0…95 % non-condensing
Storage Altitude: 0…3000 m
Acoustic Level: 40 dB
IP Degree: IP20
Package Weight: 0.7 kg
Warranty: 2 Years
