STI Stopper® Station Push Button with Universal - SS2448EX-EN

STI SS2448EX-EN Push Button Station with Universal Cover

Overview

The SS2448EX-EN is a push button station for door-release circuits in magnetic lock systems. It operates at 30VDC and mounts with a universal stopper cover that accommodates both flush and surface installation profiles. Use this when you need a straightforward, NEMA Type 23–rated button interface between an access control panel and a magnetic strike on a single door or access point.

Compatibility

The SS2448EX-EN integrates with any 30VDC magnetic lock strike and standard access control panel output. The universal cover design works with the supplied mounting plate (KIT-102720, 12mm worldwide standard) and optional extended-depth back boxes (KIT-71100A or KIT-71101B) for different wall thicknesses and recess depths. Compatible with Stopper® series button families across surface-mount and flush-mount configurations. Consult mounting documentation for existing door frame retrofits or non-standard cavities.

Installation Notes

Standard installation requires 3/16 in. diameter drill holes and a mounting depth of approximately 1.25 in. when anchors are not used. The 12mm worldwide mounting plate (KIT-102720) ships standard; no additional spacer is needed for surface-mount configurations on compatible models. Surface-mount buttons use KIT-71100A as an alternative if the standard plate does not fit your cavity. Extended-depth models require KIT-71101B plus the 12mm spacer for proper alignment. Ensure 30VDC supply voltage is stable and protected by appropriate circuit breakers or relay logic in your access control panel.

What's in the Box

• 1x SS2448EX-EN push button station with universal stopper cover
• 1x KIT-102720 mounting plate/spacer (12mm worldwide standard)
