STI EF141208-O EnviroArmour Fiberglass Opaque Credential

Overview

The STI EF141208-O is an opaque credential module designed for integration into non-metallic enclosures, providing a secure and compliant method for conduit and grounding wire installation. This hardware module ensures that installations meet electrical code requirements, particularly when dealing with non-metallic conduit connections, preventing enclosure damage and maintaining system integrity. Its specific application is within secure access control deployments where robust and code-compliant wiring practices are paramount.

Compatibility

This credential module is designed for use with STI EnviroArmour non-metallic enclosures. It facilitates the secure mounting and grounding of conduit and associated wiring, ensuring compliance with electrical codes for these specific enclosure types. It is not compatible with metallic enclosures or other brands of enclosures.

Installation Notes

Installation requires cutting conduit holes in the enclosure wall, with specific recommended hole sizes for various conduit diameters (e.g., 7/8” diameter hole for a ½” conduit). For metallic conduit, a conduit connector (hub) is secured to the conduit and then to the enclosure using a locknut, with a grounding lug attached. For non-metallic conduit, the conduit is secured to the connector before or after the connector is secured to the enclosure; a grounding bushing is not required. Proper alignment of the conduit is critical to prevent stress on the enclosure walls. Installation must adhere to The Canadian Electrical Code for grounding and bonding.

What's in the Box

• 1x STI EF141208-O EnviroArmour Fiberglass Opaque Credential
