Panduit C2CAC07F04IRW1 Net-Contain Integral Roof Aisle Containment Wall Panel
Overview
The Panduit C2CAC07F04IRW1 is a 4-foot (approximately 700mm) integral roof wall panel designed for the Panduit Net-Contain aisle containment system. Aisle containment is one of the highest-impact efficiency improvements available in a production data center: by sealing the cold aisle or hot aisle, you stop cold and hot air from mixing before it reaches the equipment intakes, which directly cuts cooling overhead and reduces the risk of hotspots at high-density rack rows. The C2CAC07F04IRW1 is the roof panel component — the piece that bridges the gap between the tops of your cabinet row and the ceiling or overhead structure, completing the containment envelope on that segment.
This panel belongs to Panduit's Net-Access and data center infrastructure lineup, which is engineered around modular, field-configurable containment rather than custom-fabricated enclosures. That matters in practice: you can reconfigure rows, extend the system, or swap panels as the floor layout evolves without ordering bespoke sheet metal each time.
Key Features
- Integral Roof Design: The roof section is built into the panel assembly rather than added as a separate retrofit piece — this means fewer seams, fewer potential air-bypass gaps, and faster installation. Every gap in a containment system is a leak path; fewer joints means better containment effectiveness.
- 700mm / 4-Foot Coverage: Sized to match standard 700mm-wide aisle containment bays, the C2CAC07F04IRW1 fits rack rows without custom trimming. Confirm your aisle bay width before ordering — 600mm and 700mm configurations are not interchangeable in this product family.
- Net-Contain System Compatibility: Designed specifically for Panduit's Net-Contain aisle containment ecosystem. This is important because mixed-brand containment panels rarely seal cleanly at the joints — using the matched Panduit panel ensures the mechanical interface at adjoining sections is manufacturer-engineered, not a field improvisation.
- Aisle Containment Efficiency Benefit: Completed aisle containment (cold or hot) can reduce PUE meaningfully in a mature data center. The roof panel is the component most commonly skipped or approximated in partial deployments; completing it is typically where the measurable efficiency gain actually materializes.
- Modular Construction: Net-Contain panels are designed to be installed, relocated, or extended as row configurations change. In growing facilities or co-location environments where rack density and layout shift regularly, that modularity avoids the sunk-cost problem of custom-fabricated containment.
- Commercial-Grade Construction: Panduit's Net-Contain line is targeted at production data centers and enterprise server rooms, not light-duty or temporary deployments. Build quality is consistent with raised-floor and above-ceiling mechanical environments.
Integration & Compatibility
The C2CAC07F04IRW1 is a component panel within the broader aisle containment system — it does not install in isolation. A complete containment run requires the matching side panels, end caps, and any overhead structure or cable tray integration your specific row configuration demands. Verify that your existing Net-Contain installation uses 700mm bay spacing before ordering this panel; pairing a 700mm roof panel with 600mm side panels will leave gaps that undermine the containment seal entirely.
This panel is not a network cabinet or rack enclosure — it is a containment accessory that works above and around your existing cabinet row. If you are planning a new aisle containment build, review Panduit's Net-Contain system documentation to confirm which base components are required before adding roof panels.
Frequently Asked Questions
Q: What aisle width does the C2CAC07F04IRW1 fit?
A: The C2CAC07F04IRW1 is sized for 700mm (approximately 4-foot) aisle containment bays in the Panduit Net-Contain system. Verify your aisle bay dimension before ordering — 600mm panels are a separate SKU and are not mechanically interchangeable.
Q: Is the C2CAC07F04IRW1 a complete containment kit or just the roof panel?
A: This is the integral roof wall panel component only. A complete aisle containment run requires additional panels, end caps, and system hardware from the Panduit Net-Contain family. It does not ship as a standalone containment solution.
Q: Can this panel be used for both cold aisle and hot aisle containment?
A: The C2CAC07F04IRW1 is a roof panel for the Net-Contain aisle containment system; the physical panel itself does not specify cold or hot aisle. However, your containment design (cold aisle containment vs. hot aisle containment) determines airflow direction and overall system architecture — confirm your design before specifying all components.
Q: Does the C2CAC07F04IRW1 require special tools to install?
A: Panduit Net-Contain panels are designed for field installation without specialized tooling, but specific fastening requirements depend on your ceiling structure and adjoining panel configuration. Consult the Net-Contain installation guide for your specific row layout.
Q: What is the warranty on the C2CAC07F04IRW1?
A: Warranty terms for Panduit infrastructure products should be confirmed with Panduit directly or via product documentation for this specific SKU, as duration is not stated in the available evidence for the C2CAC07F04IRW1.
The C2CAC07F04IRW1 is specifically the 700mm integral roof panel for Panduit's Net-Contain aisle containment system — and the roof section is the component I see most often either missing or improvised in otherwise complete containment builds. Skipping or approximating this piece negates a meaningful portion of the containment benefit because warm exhaust air bypasses the separation envelope right at the top of the row, where convective mixing is strongest.
Technical Highlights:
- 700mm Bay Fit: Matches standard 700mm Net-Contain aisle bay spacing precisely — no field trimming, no shimming, no gap-filling foam tape required when the correct panel is ordered for the correct bay width.
- Integral Roof Construction: The roof element is integrated into the panel rather than clipped or bolted on separately, which reduces the number of potential air-bypass seams in the containment envelope — each additional joint is a potential leak point in a pressurized or negative-pressure containment design.
- Net-Contain System Architecture: Designed as a matched component within Panduit's modular Net-Contain ecosystem, which means the mechanical interface at adjacent panels is engineered to specification rather than adapted in the field.
Deployment Considerations:
- Confirm 700mm bay width against your actual row measurement before ordering — this panel is not adjustable, and the 600mm variant is a separate SKU. A single wrong panel on a containment order can stall the entire row completion.
- The roof panel alone does not create a sealed containment run — it requires the matching side panels, end caps, and any blanking panels for open rack Us within the row. Budget and specify the full panel set before procurement, not piecemeal.
This panel is the right specification for enterprise data center operators and colocation facility teams completing or extending a Panduit Net-Contain row in a 700mm aisle configuration — particularly in high-density rows where the efficiency loss from an incomplete containment roof is measurable in cooling load and PUE.
