Panduit CUEORF06DPW1 Net-Contain™ Aisle Containment Roof Section
The Panduit CUEORF06DPW1 is a white PVC roof section designed for datacenter hot or cold aisle containment installations using the Net-Contain™ system. Engineered for 6-foot (1800mm) wide aisles, this expandable roof cap integrates with suspended ceiling panels to create a complete thermal barrier between server exhaust and intake zones. The extendable design accommodates up to four inches of field adjustment, addressing the dimensional tolerances common in retrofit containment projects where rack spacing or ceiling grid alignment may vary. For facilities managers and datacenter integrators deploying structured cooling strategies, this component closes the overhead gap that undermines containment efficiency and drives up HVAC costs.
Key Features
- 73.86" length spans 6-foot aisles with up to 4" extension capability for installation tolerance
- White PVC/vinyl construction matches standard datacenter ceiling aesthetics
- 24.41" height (620mm) fits typical raised-floor-to-ceiling dimensions
- 70.8" width (1.8m) provides full-width coverage for standard server rack rows
- RoHS compliant for sustainable facility certifications
- Integrates with Net-Contain™ suspended ceiling panels for complete aisle enclosure
Datacenter aisle containment has shifted from optional efficiency upgrade to baseline requirement as rack densities exceed 8-10kW. The CUEORF06DPW1 roof section addresses the most common containment leak point—the open top where hot exhaust mixes with conditioned intake air. PVC/vinyl construction delivers dimensional stability across typical datacenter temperature ranges (65-80°F operating zones) while remaining lightweight enough for single-installer handling during retrofits. The 73.86-inch base length aligns with standard 72-inch rack-to-rack spacing while the four-inch extension accommodates ceiling grid misalignment or non-standard rack positioning without custom fabrication. Field adjustability matters in brownfield deployments where you're working within existing infrastructure constraints rather than purpose-built white-space layouts.
The Net-Contain system's modular architecture lets you phase containment deployment across server rows without disrupting live environments. This roof section pairs with vertical panels and door assemblies to create a pressure boundary that separates ASHRAE-recommended cold aisle temperatures (64-80°F) from hot aisle exhaust (80-115°F). Facilities targeting PUE improvements below 1.4 or implementing ASHRAE TC 9.9 thermal guidelines will find row-based containment more cost-effective than room-level cooling upgrades. The white finish integrates with commercial ceiling tiles and lighting systems, maintaining a clean appearance that matters in customer-facing colocation environments or executive-visibility datacenter tours. RoHS compliance supports LEED and sustainable facility certifications increasingly required in enterprise procurement and municipal datacenter builds.
Panduit's Net-Contain components ship with installation hardware and work with both hot-aisle and cold-aisle containment strategies, giving integrators flexibility to match the specific CRAC/CRAH placement and airflow design of each facility. The 1800mm aisle width accommodates standard 42U racks with adequate service clearance for front-access maintenance without compromising the thermal seal during live operations.
