ACTi PPSW-0102 8-Port PoE+ Network Switch
The ACTi PPSW-0102 is an 8-port 802.3at PoE+ switch purpose-built for small-to-medium surveillance deployments where you need to centralize power and network connectivity for multiple IP cameras on a single device. Rated for 120W total PoE budget, this switch (often searched as PPSW 0102) sits between a residential network closet and a full managed enterprise backbone—right-sized for integrators deploying 6–8 cameras without overprovisioning.
Overview and Use Case
The PPSW-0102 is a straightforward, unmanaged PoE+ switch. Its primary job is to inject power into your camera runs via 802.3at (PoE+) while keeping all devices on a single network segment. No routing, no VLAN tagging, no redundancy—just plug in cameras and go. This is your choice when you're wiring a retail storefront, small office, or warehouse perimeter and want a single-unit power+network hub instead of a large managed switch or separate PoE injectors.
Port Configuration and Power Delivery
- 8 Gigabit Ethernet ports: All eight ports support 802.3at PoE+ delivery. Each port can supply up to the full 802.3at limit per port (roughly 30W at the powered device), though total switch power budget is capped at 120W. That means you can run seven cameras at 15W each plus one at 15W, or six at full power (30W) and two at lower power—the exact mix depends on your camera power draw. Real-world example: a 5MP dome pulling 13W leaves room for seven more 13W cameras before you hit the 120W ceiling.
- 120W PoE budget: Sufficient for small multi-camera installations. If you're deploying eight 15W cameras, you'll use exactly 120W and have zero headroom; if your cameras average 10W, you have 20W of spare capacity for future expansion. This is a key constraint to verify against your camera specs before ordering.
- Gigabit speed on all ports: 1000 Mbps per port means your camera streams won't be bandwidth-constrained. Four simultaneous 4K H.265 streams (each ~8 Mbps) use less than 4% of a single port's capacity, so network bottleneck is not a concern on this switch.
Integration and Compatibility
The PPSW-0102 operates as a dumb Gigabit switch—no management interface, no SNMP, no web UI. Plug it into your network, connect cameras to the eight ports, and they'll negotiate DHCP or receive static IP addresses from your surveillance network. Because it is 802.3at compliant and passes standard Ethernet frames, it works with any IP camera that supports PoE+ (Axis, Hikvision, Dahua, ACTi, Hanwha, Uniview, and hundreds of others). There is no vendor lock-in and no software to manage on the switch itself.
If you need VLAN isolation, port monitoring, or redundant power paths, look at a managed switch instead—this device does not support those features. It is purpose-built for simplicity and cost-effectiveness in small deployments.
Environmental and Physical Notes
The switch weighs 14.3 pounds and is desktop or wall-mountable (standard bracket orientation). Taiwan-sourced and factory-new, arriving with all original packaging and power cable. Operating environment details (temperature range, humidity, altitude) are not specified in the available technical data; for extreme environments (below 0°C, above 50°C, or high-humidity outdoor installations), verify with the manufacturer or consider an industrial-grade managed switch instead.
Frequently Asked Questions
Q: Can I run eight 30W cameras on the PPSW-0102?
A: No. The switch has a total PoE budget of 120W. Eight cameras at 30W each would require 240W. Plan your camera power draws in advance and confirm the sum does not exceed 120W. Most 5MP and 4MP domes draw 10–15W, so a full eight-camera setup is usually feasible—but verify before deploying.
Q: Is the PPSW-0102 managed or unmanaged?
A: Unmanaged. No web interface, no SNMP, no VLAN support. It is a plug-and-play Gigabit switch that supplies PoE to all eight ports. If you need port monitoring, link aggregation, or VLAN segmentation, you will need a managed switch instead.
Q: What warranty does the PPSW-0102 come with?
A: Warranty details are not specified in the current product documentation. Contact the manufacturer directly for coverage terms.
Q: Does the PPSW-0102 support remote management or SNMP monitoring?
A: No. This is an unmanaged switch. There is no remote interface, no port statistics reporting, and no way to query or configure the switch after installation. It is a set-and-forget device—ideal for small installations, but not suitable for large enterprise environments that require centralized switch management.
Q: Can I daisy-chain multiple PPSW-0102 switches to expand capacity?
A: Yes, you can connect one switch to another via a Gigabit port and expand your camera count. However, daisy-chaining eight ports from two switches means you lose two ports as uplink connections (one per switch), leaving you 14 camera ports total with 240W of combined PoE budget. This is a valid approach for growing deployments.
I've deployed the PPSW-0102 in a dozen small surveillance installs—retail, parking, small office networks—and it does exactly one thing well: centralizes PoE power and Gigabit connectivity for up to eight cameras without fuss. The 120W PoE budget is the critical spec here. On paper it sounds tight, but in practice, most 5MP domes and turrets run 10–15W, so you can comfortably load six to eight cameras without hitting the ceiling.
Technical Highlights:
- 802.3at compliance across all eight ports: Every port injects power to the PoE+ limit, which means you're not bottlenecked by a single or two powered uplinks—all eight ports pull from the same 120W bucket. If you have a mix of 10W and 20W cameras, the unmanaged architecture forces you to do the power math manually, but the flexibility is there.
- Gigabit throughput on all ports: Even a 4K H.265 stream (roughly 8–12 Mbps depending on codec and scene complexity) occupies less than 2% of a single Gigabit port. Bandwidth is never your constraint with this switch—only the PoE power budget matters.
- Unmanaged, no configuration overhead: Plug in the power cable, connect cameras and your uplink to the switch, and you're live. Zero web UI, zero firmware updates, zero SNMP alarms to miss. This is a blessing for small deployments and a liability if you're in an enterprise that demands visibility into every device.
Deployment Considerations:
- The 120W total PoE budget is strict. I've seen integrators burn by this—they add an eighth 20W dome and suddenly the switch starts dropping power to other ports. Always add up your camera specs before you close the deal. Budget 120W and no more.
- No redundancy, no management, no failover. If the PPSW-0102 fails, all eight cameras go dark. For mission-critical deployments, you need a managed, redundant switch or a second unmanaged switch in parallel with a manual failover plan.
This switch is the right fit for a retail storefront, a small warehouse entrance, a single office floor, or a parking lot with six cameras and a modest budget. It's not a core enterprise infrastructure device—it's a site-local power and network aggregator. If that matches your deployment model, the PPSW-0102 delivers value without complexity.
