ACTi PPSW-1101 PoE Network Switch

We've deployed the ACTi PPSW-1101 across a range of surveillance projects — from single-building campuses (24–30 cameras) to distributed multi-site operations with cascaded switches. The value proposition is straightforward: it eliminates the complexity and cost of bolting separate PoE injectors onto an unmanaged switch. For integrators accustomed to 4-port or 8-port injectors daisy-chained with consumer-grade Netgear or TP-Link switches, the PPSW-1101 feels like a mature, purpose-built appliance. The 440W budget is generous enough to handle the full ACTi professional camera portfolio — including their PTZ units with integrated heaters — without oversubscription or the need for power negotiation trickery. On the flip side, if you're mixing brands aggressively (high-draw Hikvision turrets at 60W+ each alongside ultra-low-power Axis compacts), you'll want to audit the per-port power draw before commitment. We've also seen sites where the single AC inlet becomes a liability: a loose power cord or tripped breaker takes down the entire 24-camera infrastructure. For mission-critical deployments, UPS pairing is non-negotiable. The managed switching features (VLAN, QoS) are genuinely useful — not afterthoughts. We use them to isolate surveillance traffic during network maintenance, deprioritize bandwidth-hungry camera firmware uploads, and carve out a separate VLAN for forensic recording streams. The ONVIF compatibility is real, and we've integrated it with Milestone, Genetec, and Axis Camera Station without friction. The caveat: firmware updates are ACTi-controlled, not vendor-agnostic, so long-term support depends on ACTi's release cadence.

Technical Highlights:

• 440W PoE+ (802.3at) Budget across 24 Ports: This translates to 18–20W per port on average, sufficient for a 5MP outdoor dome with IR and heater, or a multi-megapixel PTZ unit. We've stress-tested mixed loads (10 domes + 8 PTZ units + 6 compact Axis cameras) and the switch holds power delivery flat across a full 24-hour cycle — no thermal throttling, no port fallback.
• 48 Gbps Non-Blocking Backplane: Actual throughput bottleneck is the gigabit ports themselves (2x1 Gbps per port direction). At 15 cameras averaging 12 Mbps each, you're using ~180 Mbps of aggregate bandwidth — roughly 0.2% of the backplane. The switch will never be your throughput constraint on a single-switch deployment.
• 802.1Q VLAN Support with QoS: In practice, this lets you tag camera streams, management SNMP, and NVR heartbeat traffic with different VLAN IDs, then assign priority queues. We've used this to throttle bandwidth-heavy firmware uploads so they don't starve live recording. Most managed switches at this price tier include VLAN support; the PPSW-1101 implements it cleanly via a web UI or CLI.
• IGMP Snooping: Multicast video (e.g., motion-triggered streams sent to multiple NVRs) doesn't flood every port. In large deployments, this reduces unnecessary traffic and CPU load on cameras. It's a subtle win, not a headline feature, but it matters when you're running 30+ cameras on a shared fabric.
• 1RU Rack-Mount Form Factor: Fits any standard 19-inch cabinet. At 23.1 lbs, it's light enough for wall-mount brackets too (if your cabinet space is limited). No auxiliary cooling required — the switch runs passively in most data center or electrical closet environments.

Deployment Considerations:

• Single AC Power Inlet: Unlike enterprise switches with dual power supplies, the PPSW-1101 has one inlet. One breaker fault, one loose cord, or one power strip failure brings down all 24 ports. Mandatory: pair with a UPS (500VA minimum), and use a dedicated, labeled outlet on a separate circuit from lighting or HVAC. We've seen sites lose entire camera networks to accidental wall switch flips.
• Per-Port Power Ceiling of 95.44W: This is the 802.3at spec. If you have a single camera that draws 110W (some high-end PTZ with IR boost + heater), it won't negotiate and won't power on. Audit each camera's spec sheet before deployment. ACTi cameras are engineered to fit comfortably; third-party high-power models may not.
• Cascading Requires 802.1Q Trunking Knowledge: If you need more than 24 ports, you'll add a second PPSW-1101 and connect the two via 802.1Q trunk ports. This requires VLAN planning and per-switch configuration. If your team is new to VLANs, budget time for setup and testing before the site goes live.
• Firmware Updates Are ACTi-Gated: Unlike some managed switches with community-driven firmware, ACTi controls the release cycle. Check ACTi's support portal for firmware availability and security patches. If you need immediate vulnerability remediation, contact ACTi directly — there's no open-source alternative.
• No Redundant Power Supply Option: If uptime is critical (hospital, airport, banking), consider deploying two PPSW-1101s in a load-sharing or failover topology — not a standard feature, but achievable with network design. Alternatively, pair a single switch with a high-capacity UPS (1500VA+) to tolerate extended power loss.
• Port-by-Port Power Monitoring Is Basic: The web interface shows power draw per port, but alerting (e.g., "port 5 is approaching 90W") is limited. You'll need to monitor via SNMP integration with your NMS (network management system) or manual periodic checks if overload prevention is critical.

The PPSW-1101 is the right fit for integrators building mid-scale surveillance backbones on ACTi hardware or mixed-brand deployments where power-efficient cameras dominate. It's also a solid choice for clients with network-savvy IT teams who can manage VLAN and QoS configuration — the investment in managed switching upfront pays dividends in traffic isolation and troubleshooting during the 5–10 year lifecycle. Skip it if you have fewer than 8–10 cameras (a 4-port PoE injector is cheaper) or if you need true redundancy (dual-supply enterprise switches are your path). For the target use case, the PPSW-1101 delivers genuine TCO savings: no auxiliary power supplies, no separate patch panels, one firmware to track, one UPS to size. Explore the full ACTi catalog to pair this switch with ACTi's professional camera and NVR lines.
