Pelco SRXE4-4V9-EMD-1 4MP Outdoor Dome Camera

Pelco SRXE4-4V9-EMD-1 4MP Outdoor Dome Camera

The Pelco SRXE4-4V9-EMD-1 is a 4MP outdoor dome camera from the Sarix Enterprise 4 series, engineered for critical infrastructure and government applications requiring enterprise-grade cybersecurity and advanced analytics. Built on a 1/1.8-inch progressive scan CMOS sensor with 130 dB SureVision wide dynamic range, this camera delivers exceptional image clarity in challenging lighting conditions while maintaining compliance with FIPS 140-3 Level 3 encryption standards.

Key Features

• 4MP resolution at 2560 x 1440 up to 60 fps
• 4.4–9.3 mm motorized varifocal lens with 32–109° horizontal field of view
• 130 dB SureVision WDR for extreme contrast environments
• Extreme low-light performance: 0.003 lux color, 0.001 lux monochrome
• Pelco Smart Analytics: Person/Vehicle Detection, Direction Violation, Loitering, Beam Crossing, Crowd Detection, Audio Analytics, Tamper Alert
• Multiple video compression: H.265, H.264, Motion JPEG

Durability & Environmental Protection

• IP66, IP67, IP68 (2m/2hr), IPX9K, and NEMA 4X ingress protection
• IK11 impact rating for vandal resistance
• Operating temperature range: -50°C to +65°C (with PoE+ or external power)
• Outdoor-rated construction for harsh weather conditions

Cybersecurity & Compliance

• FIPS 140-3 Level 3 cryptographic validation
• Trusted Platform Module (TPM), Secure Boot, HTTPS, 802.1X authentication
• NDAA Section 889 and TAA compliant
• ONVIF Profile S, T, G, and M for standards-based integration

Power & Connectivity

PoE+ powered with Ethernet connectivity. MicroSD card storage support for local backup.

Applications

Ideal for perimeter security at government facilities, critical infrastructure, airports, ports, and border crossings. The motorized varifocal lens and advanced analytics enable flexible area coverage and automated threat detection. Enterprise cybersecurity features meet stringent federal compliance requirements.

5-year warranty included.

Product Documentation

James Everett

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

I spec the SRXE4-4V9-EMD for clients who need hardened perimeter surveillance with federal-level cybersecurity. The FIPS 140-3 Level 3 validation and TPM aren't just checkboxes—they're essential for government sites, critical infrastructure, and DOD contractors where non-compliant gear simply won't pass procurement. The 130 dB WDR handles the toughest lighting I see in outdoor deployments: loading docks with backlit doorways, gate access points with headlight glare, and perimeters transitioning from shadow to direct sun.

The motorized varifocal lens (4.4–9.3 mm) gives you setup flexibility without climbing back up, but understand that at 9.3 mm you're still only at 32° horizontal—this isn't a wide-area overview camera. It excels at focused choke points and defined zones where you need facial detail or license plate capture at 20–40 feet. One watch-out: the -50°C rating requires PoE+ or supplemental power; standard PoE won't reliably drive the heater in extreme cold. Plan your switch budget accordingly for northern or high-altitude installations.

Key Specifications:
Color: White
