Panduit FC2WA-12-10B2 Opticom OM5 MPO/6 DUP LC Fiber Cassette
Overview
The Panduit FC2WA-12-10B2 is an OM5 fiber optic cassette designed for high-density data center and enterprise network applications. It terminates 12 fibers, providing a transition from an MPO-12 male connector to six LC duplex connectors. This cassette is constructed from durable polycarbonate and is black in color, facilitating easy integration into standard fiber optic enclosures and panels. Its primary function is to enable efficient fiber management and connectivity within structured cabling systems, supporting up to 10 Gbps or higher speeds depending on the network infrastructure.
Compatibility
This Panduit Opticom® cassette is designed for use with Panduit fiber optic enclosures and panels that accept MPO-based cassettes. It is compatible with OM5 multimode fiber, which is optimized for short-wavelength division multiplexing (SWDM) transceivers, enabling higher bandwidth over existing fiber infrastructure. The MPO-12 male connector requires a corresponding female connector on the incoming trunk cable. The six LC duplex connectors are standard for network switches and transceivers requiring dual-fiber connections.
Installation Notes
The FC2WA-12-10B2 cassette slides directly into compatible Panduit fiber optic enclosures. Ensure the incoming MPO trunk cable has a female connector to mate with the cassette's male MPO. Handle the fiber connectors with care to avoid contamination or damage. The polycarbonate material offers robust protection for the internal fiber splices and connections.
