Viking E-70-BN-EWP Bronze Entry Phone 125KHz Prox Reader IP66

Viking Electronics E-70-BN-EWP Oil Rubbed Bronze Entry Phone with Proximity Card Reader

Overview

The Viking Electronics E-70-BN-EWP is a telephone-line-powered, hands-free entry phone and proximity card reader in a single oil rubbed bronze faceplate — built for exterior doors, vestibules, and controlled-access lobbies where you need both visitor communication and credential-based entry in one flush-mount device. Rated IP66 and tested from -30°F to 150°F with 100% humidity tolerance, this unit goes where standard intercoms cannot. It mounts into a standard double gang box or on a surface with the optional VE-5x5 enclosure for Enhanced Weather Protection (EWP).

Key Features

• 125KHz 26-bit Wiegand Proximity Reader: Compatible with Viking PRx-C, PRx-C-ISO, PRx-FOB, and AWID 125KHz credentials. The 26-bit Wiegand output wires directly to any standard access control panel — no proprietary controller needed. Read range of 1.25" to 2.0" keeps presentation deliberate, reducing false reads at high-traffic doors.
• Telephone Line Powered: Requires only a standard telephone loop — 18V DC minimum talk battery, 20mA minimum loop current, 25V AC RMS minimum ring voltage. No separate power supply to mount, wire, or fuse. This significantly simplifies rough-in at doors where pulling a dedicated power circuit is impractical.
• IP66 Ingress Protection with EWP Board: IP66 means sustained water jets from any direction won't penetrate. The EWP board adds an additional layer of PCB protection against moisture ingress — the right choice for exposed exterior installations in wet climates or car-wash-adjacent environments.
• Operating Range -30°F to 150°F at 100% Humidity: Most commercial intercoms rate to -4°F or 14°F. The E-70-BN-EWP's -30°F floor means it stays functional in cold-storage entry points, loading dock doors in northern climates, and unheated parking structures where competing units fail in January.
• Blue LED Indicator with Audible Beep Confirmation: Card read confirmation via both visual (blue LED) and audible (beep) feedback. Users know immediately whether their credential registered — reduces help desk calls and door-propping at busy entry points.
• Automatic Disconnect (CPC): CPC disconnect after a 300ms minimum pulse ends calls automatically — no need for the called party to manually hang up. This matters on PABX integrations and automated door-control systems where call state drives relay logic.
• Speaker Volume 62dB Max at 1 Meter: Adequate for outdoor ambient noise at standard entry distances. Microphone and speaker volumes are field-adjustable, so you can tune to the acoustic environment without returning to programming mode.
• 18-Gauge 304 Stainless Steel Faceplate with Solid Brass Push Button: The 4.875" x 4.938" faceplate and solid push button resist vandalism and surface corrosion — the stainless construction is why this unit holds up in coastal, industrial, and high-abuse environments where painted or plastic-faced intercoms fail prematurely.

Integration & Compatibility

The E-70-BN-EWP (often searched as E 70 BN EWP) outputs standard 26-bit Wiegand to any compatible access control panel. Supported proximity technologies include Viking PRx-C, PRx-C-ISO, PRx-FOB, and AWID 125KHz cards and fobs. The telephone interface connects to any standard PABX, key system, or plain old telephone service (POTS) line with sufficient loop current. Pair with a Viking intercom system controller or integrate into your existing access control platform via the Wiegand output. For exposed exterior locations, the optional VE-5x5 surface mount enclosure provides additional weather shielding. Review our door entry phone category for complementary Viking entry devices, and consult the Viking Electronics line for compatible door controllers and accessories.

Frequently Asked Questions

Q: What proximity card formats does the E-70-BN-EWP support?

A: The unit reads 125KHz 26-bit Wiegand credentials. Supported technologies include Viking PRx-C, PRx-C-ISO, PRx-FOB, and AWID 125KHz cards and fobs.

Q: Does the E-70-BN-EWP require a dedicated power supply?

A: No. The device is telephone line powered and requires a minimum 18V DC talk battery and 20mA loop current from the connected telephone system. No separate power supply is needed.

Q: What is the IP rating and what weather conditions can the E-70-BN-EWP handle?

A: The E-70-BN-EWP is rated IP66 and includes an Enhanced Weather Protection (EWP) board. It operates from -30°F to 150°F at up to 100% humidity, making it suitable for cold-climate exterior installations and high-moisture environments.

Q: Can the E-70-BN-EWP be surface mounted?

A: Yes. It flushes into a standard double gang electrical box or mounts on a surface using the optional VE-5x5 enclosure. The faceplate measures 4.875" x 4.938".

Q: What is the proximity card read range on the E-70-BN-EWP?

A: The proximity reader has a read range of 1.25" to 2.0", which keeps credential presentation deliberate and reduces inadvertent reads at high-traffic entry points.

Q: How does the automatic disconnect work on this entry phone?

A: The E-70-BN-EWP uses CPC (Calling Party Control) disconnect with a 300ms minimum pulse to terminate calls automatically. This is useful in PABX and automated door-control environments where call state drives relay or access logic.

Karl Wilson

The E-70-BN-EWP stands out in the entry phone category specifically because of its -30°F to 150°F operating range combined with IP66 and the EWP board — that combination is uncommon at this form factor and price tier. Most integrators only discover the cold-floor limitation of competing units after a January callback from a client in Minnesota or Alberta.

Technical Highlights:

• 26-bit Wiegand at 125KHz: Universal output format means you wire this directly to any access panel — Lenel, Software House, HID VertX, Honeywell Pro-Watch — without a protocol converter. PRx-C and AWID card compatibility covers the installed base you're most likely to encounter on retrofit jobs.
• CPC Disconnect at 300ms: On PABX-driven door releases, the call-state termination is what triggers the relay. A clean 300ms CPC pulse keeps the relay logic predictable and avoids stuck-open conditions caused by missed hang-up signals on older PBX firmware.
• 18-Gauge 304 Stainless Steel: The faceplate and solid push button are the same alloy specification used in commercial food-service and marine hardware. It won't pit in coastal salt air or discolor from cleaning chemicals — relevant in healthcare, hospitality, and industrial wash-down environments.

Deployment Considerations:

• Confirm your telephone loop can deliver at least 20mA and 18V DC at the device end — long cable runs to distant telco rooms can drop below minimums, especially when bundled with other loop-powered devices on the same pair. Measure at the device terminal, not the panel.
• The 1.25" to 2.0" read range is deliberately short — users accustomed to long-range readers (3"–6") will need orientation signage or a credential presentation indicator on the faceplate surround. Without coaching, you'll get repeat service calls about the reader 'not working.'

This unit is the right call for cold-storage facility entry doors, covered parking structure pedestrian gates, and healthcare facility exterior access points where the combination of credential management and hands-free communication needs to survive genuine environmental abuse — not just light rain.
