Description

Viking Electronics E-60-BN-EWP Oil Rubbed Bronze Entry Phone with EWP

Overview

The Viking Electronics E-60-BN-EWP is a telephone-line-powered, vandal-resistant entry phone finished in oil rubbed bronze — a satin dark brown powder paint that integrates cleanly into commercial entryways, multi-tenant lobbies, and gated access points where aesthetics matter as much as durability. The E-60-BN-EWP (often searched as E 60 BN EWP) draws power directly from the telephone line, eliminating a separate power supply and simplifying rough-in on any standard POTS or analog CO line. The Enhanced Weather Protection (EWP) configuration adds foam rubber gaskets, sealed connections, and gel-filled butt connectors, pushing the unit to an IP66 ingress protection rating and 100% humidity tolerance — suitable for installations exposed to driving rain, coastal condensation, or extreme temperature swings from -30°F to 150°F.

This is a flush-mount device designed for a standard double gang electrical box, keeping the wall profile low and the install clean. For surface applications or added weather protection, the optional VE-5x5 surface mount enclosure pairs directly with the E-60-BN-EWP and provides additional environmental shielding. The 18-gauge 304 stainless steel faceplate (4.875

Specifications
Faceplate Dimensions: 4.875” x 4.938” x 0.17”
Phone Dimensions: 2.84” x 1.8” x 1.65”
Shipping Weight: 1.2 lbs
Operating Temperature: -30° F to 150° F
Humidity: 5% to 95% non-condensing (Standard), up to 100% (EWP)
Speaker Volume: 62db maximum @ 1m
Ring Voltage: 25V AC RMS minimum
CPC Disconnect Time: 300ms minimum
REN: 0.8A
Power: Telephone line powered
Minimum Voltage: 18V DC
Minimum Current: 20mA
Mounting: Flush mount in double gang box or surface mount with VE-5x5
IP Rating: IP67 (push button switch), IP66 (EWP model)
Faceplate Material: 18 gauge 304 Stainless Steel
Push Button Material: 316 stainless steel
Speaker Screen Material: Carbon fiber reinforced plastic
Mounting Screws: 6-32 x 3/4" Marine grade 316 stainless steel
