Middle Atlantic NM Outside Elbow PN03 IVO - PN03F18V

Middle Atlantic PN03F18V NM Outside Elbow Fitting

Overview

The Middle Atlantic PN03F18V is an outside elbow fitting designed for the Eclipse PN03 non-metallic raceway system. When a cable run needs to change direction at an external corner — along a baseboard, around a door frame, or at a wall-to-wall transition — this elbow maintains the raceway profile cleanly without cutting or bending the channel body. The ivory finish matches the PN03F18V to standard commercial interior trim, making it the correct choice for finished office, retail, or institutional spaces where exposed conduit aesthetics matter. TAA-compliant construction makes this fitting eligible for U.S. government and federally funded projects that require trade agreement compliance.

Compatibility

Designed specifically for the Middle Atlantic Eclipse PN03 non-metallic raceway series. Pair with the matching PN03 base channel and cover when planning a complete raceway run — inside elbows, couplings, and flat elbows in the same PN03 family maintain consistent fit and finish. Not interchangeable with PN05 or other raceway profiles. For structured cabling and low-voltage pathways, verify that raceway fill capacity meets your cable bundle requirements before specifying PN03 fittings on high-count runs.

Installation Notes

Mounts at external corners as a direct snap-fit or screw-mount accessory to the PN03 cable management base. No specialized tools required. Position the elbow before securing the adjacent channel runs to ensure proper alignment at the corner transition. Ivory color should be confirmed against installed raceway inventory — Middle Atlantic offers the same elbow profile in other finishes; specify PN03F18V exclusively for ivory applications to avoid color mismatch on visible runs.
