Middle Atlantic NM Internal Elbow PN03 IV - PN03F17V

Middle Atlantic PN03F17V 90° PVC Internal Elbow Fitting

Overview

The PN03F17V is a 90-degree internal elbow fitting designed for Middle Atlantic's PN03 electrical duct and raceway series. It routes cables cleanly through inside corners within a rack or enclosure run — eliminating sharp bends that can stress conductor insulation or restrict future cable pulls. The ivory PVC construction matches standard PN03 ivory raceway color for a consistent finished appearance in equipment rooms and server bays.

Compatibility

Sized specifically for Middle Atlantic PN03 series raceway: 1/2 in. height × 3/4 in. width interior channel. This fitting is an internal elbow, meaning it handles 90-degree direction changes at inside corners of a raceway run — not outside corners (those require a separate external elbow). Verify your installed raceway matches the PN03 series profile before ordering; adjacent PN03 series fittings and couplers (straight splices, tees, outside elbows) mate directly without adapters.

Installation Notes

PVC snaps or slides into place following standard PN03 raceway assembly practice. No special tools required. The ivory color (ANSI/RAL equivalent) is fixed — if your installation uses a different raceway color variant, confirm finish compatibility before ordering. Route low-voltage signal cable (Cat5e/6, alarm wiring, access control runs) through the PN03 channel; this is not rated as a conduit for line-voltage branch circuits unless local code permits PVC surface raceway at that voltage level — verify with your AHJ.
