Middle Atlantic PN03F17FW Internal Elbow Fitting for Wiremold Eclipse PN03
Overview
The Middle Atlantic PN03F17FW is an internal elbow fitting designed for directional cable routing transitions within the Wiremold Eclipse PN03 raceway system. When a run of cable tray or surface raceway needs to change direction inside a wall corner or enclosure interior — without exposing a kink or unsupported cable bend — the PN03F17FW provides the structured 90° path change that keeps cable bundles protected and organized. This is the fitting to reach for when your PN03 raceway route turns an inside corner: it maintains the raceway's finished appearance and preserves cable bend radius through the transition.
Compatibility
The PN03F17FW is purpose-built for the Middle Atlantic Wiremold Eclipse PN03 cable management series. It is not cross-compatible with other Wiremold raceway families (NM, G3, or 700/2400 series) — verify the PN03 series designation on your existing raceway before ordering. This fitting integrates with the full range of PN03 raceway fittings: couplings, external elbows, flat elbows, and tees that share the same profile. It is appropriate for low-voltage signal cabling, structured network cabling, and security system wiring — camera runs, access control wiring, and similar cable management accessories commonly routed inside PN03 raceway installations in commercial and institutional environments.
Installation Notes
The internal elbow is for inside-corner transitions only — do not substitute it for an external elbow fitting where the raceway bends around an outside corner, as the channel geometry differs. Snap or screw attachment follows standard PN03 fitting installation; no special tools are required beyond those used for the rest of the PN03 raceway run. Ensure the base raceway is fully secured before fitting the elbow to avoid stress on the fitting joint. For rack and enclosure wiring projects, plan the elbow position before pulling cable — the fitting closes off access to the channel interior at that point.
