Panduit NK6APC3GY Patch Cord

Overview

The Panduit NK6APC3GY is a 3-foot Category 6A U/UTP patch cord, finished in gray. It's designed for high-speed data networks, supporting 10GBASE-T Ethernet and wireless deployments. Its CM/LSZH (Communications Multipurpose/Low Smoke Zero Halogen) rating makes it suitable for installations where fire safety and low smoke emission are critical, such as in commercial buildings and data centers. This cable ensures reliable connectivity for critical applications including video streaming and Power over Ethernet (PoE) up to the proposed IEEE 802.3bt standards.

Compatibility

This patch cord is built to exceed ANSI/TIA-568-C.2 Category 6A and ISO 11801 Class EA channel requirements up to 500 MHz. It is compatible with any network device requiring Category 6A performance, including switches, routers, and servers. The stranded 26 AWG conductors provide flexibility, and the modular plugs are compliant with ANSI/TIA-1096-A, ensuring interoperability with standard RJ45 interfaces. It supports IEEE 802.3af/at and proposed 802.3bt type 3 and type 4 PoE applications, making it ideal for powering devices like IP cameras and wireless access points.

Installation Notes

Features a patented tangle-free latch for secure connection and disconnection without damage. The slender strain relief boot protects the cable termination point and is designed to fit in high-density environments. Conductors are gold-plated with 50 microinches of gold for optimal signal integrity and corrosion resistance. Cable construction is U/UTP (Unshielded Twisted Pair).
