i-PRO Mounting Base FOR WV-CW504F Flush Camera - WVQ115A

i-PRO WVQ115A Mounting Base for WV-CW504F Flush Camera

Overview

The WVQ115A is a dedicated mounting base designed for the i-PRO WV-CW504F flush-mount vandal dome camera. This accessory delivers the structural interface between the camera and ceiling, with integrated cable routing and alignment geometry that eliminates guesswork during installation. If you're deploying the WV-CW504F in a flush-mount configuration (recessed ceiling), this base is required — it's not optional hardware.

Compatibility

This base is manufactured specifically for the i-PRO WV-CW504F vandal dome (flush mount variant). The WVQ115A is not cross-compatible with the WV-CW504S (surface mount version) or other camera families. Verify your camera model before ordering — the part number on your dome should read WV-CW504F.

Installation Notes

The WVQ115A features a 3-way hinge mechanism (horizontal, vertical, and swivel rotation) that simplifies aiming and focus adjustment after initial mounting. The two-piece mounting bracket structure accommodates dual-screw connection points, reducing stress concentration on the ceiling. IP66 rating on the base ensures water ingress protection in damp ceiling cavities or environments with occasional spray. The included butyl tape provides a gasket seal at the ceiling-to-dome interface — apply this before final tightening. Install with the supplied M4 × 8 fixing screws (included); use appropriate anchors for your ceiling material (not included). The base supports the full operating temperature range of the camera (–30 °C to +50 °C / –22 °F to 122 °F).

What's in the Box

• 1x Mounting base assembly
• 1x Camera attachment connector
• 1x Camera mount bracket
• 5x Fixing screws (M4 × 8)
• 1x Butyl tape (gasket seal)
• 1x Bit for tamperproof screw
• 1x Installation guide
