Panduit CJSUD688TGY Jack Module

Overview

The Panduit CJSUD688TGY is a Mini-Com® shielded RJ45 Cat 6 jack module designed for terminating shielded 4-pair, 22-26 AWG twisted-pair cable. Its Up/Down 45° angled design is specifically engineered to improve cable routing and manage bends in confined installation spaces, preventing strain and signal degradation. This module is 100% factory tested to exceed industry performance standards, ensuring reliable data transmission for critical network infrastructure.

Compatibility

This jack module is compatible with Panduit Mini-Com Modular Patch Panels and Faceplates, forming part of the Pan-Net® copper-systems infrastructure. It supports Category 6 performance, exceeding the channel and component requirements of ANSI/TIA-568.2-D and ISO 11801 standards. The module is also compliant with IEEE 802.3af, 802.3at, and 802.3bt Type 3 and Type 4 Power over Ethernet standards, meaning it can safely handle high power delivery up to PoE++ without signal interference.

Installation Notes

The TG style termination on the CJSUD688TGY eliminates the need for a specialized termination tool, simplifying installation. Each jack is individually serialized for traceability, which is crucial for network documentation and troubleshooting. The module's compact dimensions (0.71" H x 0.62" W) are ideal for high-density patch panels and wall plates where space is at a premium.
