Lenovo 4X97A90202 SR630 V3 FIO 4 Anybay G5 BP Sas/sata CBL

Lenovo 4X97A90202 SR630 V3 FIO Anybay G5 SAS/SATA Backplane Cable

Overview

The Lenovo 4X97A90202 is an internal backplane cable assembly designed for the ThinkSystem SR630 V3 server platform, specifically supporting the 4 Anybay G5 backplane configuration. Carrying both SAS and SATA signaling over a single harness, it allows the SR630 V3 to address a mixed drive bay population — spinning SATA HDDs alongside SAS SSDs or SAS HDDs — without requiring separate cable runs for each interface type. If you are expanding or replacing the drive subsystem in an SR630 V3 configured with the FIO (Field Installable Option) backplane layout, this is the correct cable to pull.

Key Features

• Dual SAS/SATA interface: A single cable harness carries both SAS and SATA signals to the Anybay G5 backplane. That means your SR630 V3 can host SAS and SATA drives in the same backplane without a second cable — fewer internal routing conflicts and a cleaner airflow path inside a 1U chassis where space is at a premium.
• SR630 V3 FIO platform match: Engineered specifically for the ThinkSystem SR630 V3 FIO 4-Anybay G5 backplane. Connector keying and harness length are matched to this platform — substituting a generic SAS cable risks connector stress, mis-seating, or an outright mechanical mismatch. Use the OEM part.
• Factory-new assembly: Sourced factory-new — not a pulled or refurbished unit — which matters for server builds where a marginal SAS connector on a used cable can cause intermittent drive drops under vibration that are genuinely difficult to diagnose.

Integration & Compatibility

The 4X97A90202 is a platform-specific part. Verify your SR630 V3 chassis is configured with the FIO 4-Anybay G5 backplane before ordering — the Anybay G5 layout differs from standard 2.5-inch and 3.5-inch backplane variants in the SR630 V3 family, and the cable assemblies are not interchangeable. Consult the SR630 V3 maintenance manual or your Lenovo server hardware documentation to confirm backplane topology before replacing this component. This cable is not compatible with SR630 V2 or earlier SR630 revisions — the G5 backplane generation is specific to V3.

Frequently Asked Questions

Q: Is the 4X97A90202 compatible with the ThinkSystem SR630 V2?

A: No. The 4X97A90202 is designed specifically for the SR630 V3 FIO 4-Anybay G5 backplane. It is not compatible with SR630 V2 or earlier SR630 platforms — the backplane generation and connector layout differ.

Q: Does this cable support both SAS and SATA drives simultaneously?

A: Yes. The 4X97A90202 carries both SAS and SATA signaling, enabling the SR630 V3 Anybay G5 backplane to address a mixed population of SAS and SATA drives from a single cable assembly.

Q: Is this a field-replaceable part or factory-only?

A: The FIO (Field Installable Option) designation indicates this is intended for field installation. Follow the SR630 V3 maintenance manual procedures for safe handling of internal cable assemblies.

Q: What does the UNSPSC code 26121624 indicate?

A: UNSPSC 26121624 classifies this as a power and signal cable assembly component — consistent with an internal server backplane cable. This code is relevant for procurement systems that use UNSPSC taxonomy for categorization.

James Everett

The 4X97A90202 is a platform-specific cable assembly — the dual SAS/SATA interface is the detail that matters most here. When you are populating an SR630 V3 with a mixed SAS/SATA drive strategy, this single harness handles both signal types to the Anybay G5 backplane, which keeps the internal cable count down in an already-tight 1U layout.

Technical Highlights:

• SAS + SATA over one harness: Eliminates the need for separate SAS and SATA cable runs to the Anybay G5 backplane — relevant when you are mixing drive types for tiered storage or cost-performance balance in an SR630 V3 build.
• FIO designation: Designed for field installation, meaning this is a supported replacement part — not a factory-only assembly — which simplifies sparing and on-site maintenance workflows for data center teams.
• Platform specificity: Connector geometry is matched to the SR630 V3 G5 backplane generation. This is not a universal SAS cable — forcing a generic alternative risks physical connector damage or unreliable drive detection.

Deployment Considerations:

• Confirm the SR630 V3 chassis backplane topology before ordering — the Anybay G5 layout is distinct from standard 2.5-inch or NVMe-only backplane configurations in the same SR630 V3 family.
• No cable length, connector pin-count, or signal speed specifications are available from current distribution data — pull the SR630 V3 maintenance manual for exact routing and installation torque specs before field replacement.

This cable is the correct sparing or build component for SR630 V3 deployments running mixed SAS/SATA storage pools — particularly in enterprise data center or edge compute environments where the Anybay G5 backplane was selected for drive flexibility at configuration time.
