Lenovo 4X97A83828 SR630 V3 8X2.5 Sas/sata BP CBL KIT

Lenovo 4X97A83828 SR630 V3 8x2.5" SAS/SATA Backplane Cable Kit

Overview

The Lenovo 4X97A83828 is a backplane cable kit designed for the ThinkSystem SR630 V3 server configured with an 8x2.5" SAS/SATA drive bay backplane. When you're building out or replacing internal storage cabling on an SR630 V3, this kit delivers the correct signal routing between the backplane and the system's storage controllers — keeping drive connectivity clean and factory-spec without improvised cabling that can introduce signal integrity problems or void service agreements. The 4X97A83828 is the purpose-built replacement or augmentation cable set for this specific chassis configuration.

Compatibility

Designed specifically for the Lenovo ThinkSystem SR630 V3 in the 8x2.5" SAS/SATA server storage configuration. Supports both SAS and SATA drive interfaces, making it compatible with mixed backplane deployments running SAS HDDs, SATA HDDs, or SATA SSDs in the same chassis. Verify your SR630 V3 backplane variant before ordering — Lenovo offers multiple SR630 V3 backplane configurations (NVMe, SAS/SATA, and hybrid), and cable kits are not cross-compatible between backplane types.

Installation Notes

Routed internally within the SR630 V3 chassis — follow Lenovo's ThinkSystem SR630 V3 maintenance manual for cable management routing paths and connector seating order to avoid pinch points near the mid-plane. Dimensions of 12.60 x 17.30 x 3.30 in and a weight of 1.60 lb reflect the packaged kit; individual cable runs are chassis-constrained. No external tools beyond standard server servicing equipment are required, but ESD precautions apply throughout installation.
