Resolution:
19 MP (3×6MP, 3328×1872)
Type:
Multi-Sensor Panoramic Outdoor Dome Camera
Frame Rate:
30fps
Sensor Type:
3 x 1/2.8 type CMOS image sensor
Scanning Area:
5.56 mm(H) x 3.13 mm(V); {7/32 inches(H) × 1/8 inches(V)}
Minimum Illumination:
0.05 Lux
White Balance:
ATW1/ ATW2/ AWC
Maximum shutter:
1/10000s to 16/30s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off; The level can be set in the range of 0 to 31.
Dynamic Range:
Max.120 dB (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC/HLC with manual control
Fog Compensation:
On/Off (manual mode)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Auto Day/Night with IR modes
IR LED Light:
40m IR range (30IRE) / 30m (50IRE)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Panorama:
Panorama mode (H: 170 deg.)
Video Motion Detection (VMD:
On / Off,; 4 areas available
Scene Change Detection (SCD:
On / Off,; 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Selectable from Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, Face & Vehicle Detection
Privacy Zone:
On / Off,; Up to 8 zones available
VIQS:
On / Off,; Up to 8 zones available
Image Rotation:
0° (Off)/ 90°/ 180° (Upside-down)/ 270°
Camera Title (OSD:
On/Off, 40 char, 2 lines
Focus Adjustment:
—
Optical Zoom:
1x
Extra zoom:
max 5x; (when resolution is 640x360)
Focal Length:
3.1 mm {1/8 inches}
Angular Field of View:
Horizontal : 108°; Vertical : 56°
Maximum Aperture Ratio:
1 : 1.4
Focus range:
3 m {9.84 ft} – ∞
Detect (25ppm / 8ppf:
48.4 m / 158.7 ft
Observe (62.5ppm / 19ppf:
19.3 m / 63.5 ft
Recognize (125ppm / 38ppf:
9.7 m / 31.7 ft
Identify (250ppm / 76ppf:
4.8 m / 15.9 ft
System on Chip (SoC:
Ambarella CV2
Adjusting Angle:
±125° pan, ±10-105° tilt, ±90° yaw, ±30° twist
Camera Control:
Brightness, AUX On / Off
Audio Support:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX / 1000Base-T, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
3328x1872, 2560x1440, 1920x1080, 1280x720, 640x360, 320x180
H.265/H.264:
H.265/H.264, CBR/VBR, Unicast/Multicast
JPEG:
[Image Quality]; 10 steps
Smart Coding:
GOP (Group of pictures) control :; On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off; *On (Frame rate control) and On (Advanced) are only available with H.265.; Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps, G.711 : 64 kbps, +more
Audio Transmission Mode:
Off/Mic input/Audio output/Half duplex/Full duplex
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,; DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS,; NTP, SNMPv1/v2/v3, U
No. of Simultaneous Users:
Up to 24 users (Depends on network conditions)
Secure:
FIPS 140-2 Level 3, NXP EdgeLock SE050F
SDXC/SDHC/SD Memory Card:
microSDXC
Mobile Terminal Compatibility:
iPad,; iPhone,; Android™ terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals, VMD, SCD, audio detection
Alarm Actions:
Email, HTTP, TCP notification, SD recording
Monitor Output (for Adjustment:
—
Audio input:
3.5mm stereo mini jack, plug-in power mic
Audio Output:
3.5mm stereo jack, 600Ω unbalanced
External I/O Terminals:
3x Alarm I/O terminals (IN1/IN2/IN3, OUT, AUX)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035
Power Source and Power Consumption:
PoE+ 25.4W, DC 54V 470mA
Ambient Operating Temperature:
–40 to +60°C (–20 to +60°C operating)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element + moisture absorption gel
Water and Dust Resistance:
IP67/IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS 2 (2.2.7-2.2.9)
Dimensions:
When using the attachment plate only :; ø300 mm × 90 mm (H) {ø11-13/16 inches ×3-17/32 inches (H)}
Mass (approx:
3.1 kg (6.83 lbs)
Finish:
Aluminum die cast, stainless steel, PC resin
Product Type:
Multi-Sensor
Connectivity:
Wired
Night Vision:
IR
Power Type:
PoE+
PoE Class:
4
Form Factor:
Dome
IP Rating:
IP67, NEMA 4X
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
6MP
Video Compression:
H.265, H.264, MJPEG
IR Distance:
40m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
5-year warranty
Brand:
i-PRO
MPN:
WV-S8563L
Color:
Black
Power:
4W
resolution:
19 MP
ip_rating:
IP67/IP66
ik_rating:
IK10
poe_power:
PoE+ (802.3at)
ir_lowlight:
IR
compression:
H.265; H.264; MJPEG
onvif:
Yes
audio:
Audio input
analytics:
VMD
mount_type:
Rack
Color:
/BW (ICR) O / On(IR Light O ) / On(IR Light On) / Auto1(IR Light O ) /
Audio:
Audio input; Detection on/off; OSD title configurable
Camera:
Title (OSD) On / O
Operating_Temp:
-40°C to +60°C (-40°F to 140°F)
Wattage:
25.4W
Length:
1872 in
Compatible With:
outdoor
Mount Style:
wall-mount
PoE:
PoE
Speed:
4 Mbps
Screen Size:
1872 in
PoE_Power:
PoE+ (802.3at), 25.4W
WDR:
Super Dynamic 120dB
IR_Lowlight:
0.05 lux BW; 0.084 lux color; IR LED to 40m @ 30 IRE
Analytics:
VMD (4 areas); Scene Change Detection
Lens:
Three fixed modules, 108° horizontal each, adjustable mount ±125° pan / +10° to +105° tilt / ±90° yaw
Mount_Type:
Wall-mount; Adjustable multi-angle installation
Form_Factor:
Multi-Sensor Panoramic Dome
Max_FPS:
15 fps
IR_Range:
40m (30 IRE); 30m (50 IRE)
Sensor_Size:
1/2.8-inch CMOS (3×)
Min_Illumination:
0.05 lux BW (50 IRE, F2.0, 1/30s); 0.084 lux color (30 IRE, F2.0, 1/30s)
Certifications:
NDAA; FIPS 140-2 Level 3 (EdgeLock SE050F)
Cybersecurity:
FIPS 140-2 Level 3 Secure Element
VMS_Compatibility:
ONVIF Profile G/M/S/T
PoE_Wattage:
25.4W max
PTZ_Range:
No pan-tilt motor; adjustable mount only (static multi-angle, 270° fixed coverage)
eol:
true
