Type:
PTZ
Features:
AI
Features:
PTZ
Frame Rate:
Variable
Sensor Type:
Approx. 1/2.8 type CMOS image sensor
Scanning Area:
5.57 × 3.13 mm
Minimum Illumination:
0.1 Lux (BW)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
1/30 to 1/10000
Maximum shutter:
1/4000s to 16s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, The level can be set in the range of 0 to 31.
Dynamic Range:
Max.132 dB (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/ High Light Compensation:
BLC/HLC adjustable 0-31
Fog Compensation:
Fog Compensation 0-8 levels
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On / Auto
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off,; 4 areas available
Scene Change Detection (SCD:
On / Off,; 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI motion/privacy/face/people/vehicle detection
Privacy Zone:
On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available
Image Stabilizer:
On / Off (Built-in gyro sensor)
Image Rotation:
On / Off
Camera Title (OSD:
Configurable up to 40 characters
Optical Zoom:
30x (Motorized zoom / Motorized focus)
Extra zoom:
Max. 78x(30x - 78x when resolution is 1280x720)
Focal Length:
4.5mm - 135mm(3/16 inches - 5-5/16 inches)
Angular Field of View:
2.5° - 62° horizontal
Maximum Aperture Ratio:
1 : 1.8 (WIDE) – 1 : 4.7 (TELE)
Focus range:
3.0 m {118-1/8 inches} –∞
Aperture range:
F1.8 – close
Detect (25ppm / 8ppf:
Wide: 110.8 m / 363.4 ft, Tele: 3050.4 m / 10007.9 ft
Observe (62.5ppm / 19ppf:
Wide: 44.3 m / 145.4 ft, Tele: 1220.2 m / 4003.2 ft
Recognize (125ppm / 38ppf:
Wide: 22.2 m / 72.7 ft, Tele: 610.1 m / 2001.6 ft
Identify (250ppm / 76ppf:
Wide: 11.1 m / 36.3 ft, Tele: 305.0 m / 1000.8 ft
System on Chip (SoC:
Ambarella CV22
Adjusting Angle:
360° pan, -20° to +90° tilt
Panning Range:
360° Endless panning
Panning Speed:
Manual 0.065-150°/s; Preset 700°/s
Tilting Range:
Operational range -20° – +90°
Tilting Speed:
Manual 0.065–150°/s, Preset 500°/s
Preset Positions:
256 positions
Auto Mode:
Auto track/ Auto pan/ Preset sequence/ Patrol
Self Return:
10s to 60min (selectable)
Active ClearSight:
Yes
GUI / Setup Menu Language:
9 languages
Browser *1:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
3328x1872, 2560x1440, 1920x1080, 1280x720, 640x360, 320x180
H.265/H.264 Transmission Mode / Type *2:
Constant bit rate / VBR / Frame rate / Best effort
JPEG:
[Image Quality] 10 steps
Smart Coding:
GOP (Group of pictures) control:; Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/; Advanced(Fixed GOP 60s w/1s key-frame)/; Frame rate control (Variable GOP 4s-16s with frame rate control); *Advanced and Frame rate control are only availabl
Audio compression method *3:
G.726 16-128kbps, G.711 64kbps, AAC-LC 64-128kbps
Audio Transmission Mode:
Off / Mic input / Audio output / Half duplex / Full duplex
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,; DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP,; DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, I
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
Secure:
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate; GlobalSign® pre-installed,; HTTPS, User authentication, Digest authentication, Host authentication,; IEEE802.1X, System log, Image transmission log, Brute-force protection,; Alteration d
SDXC/SDHC/SD Memory Card (Option:
microSDXC memory card
Mobile Terminal Compatibility:
iPad, iPhone (iOS 8.0 or later), AndroidTM terminals
ONVIF®Profile:
G / M / S / T
Alarm Source:
3 terminals, VMD, command, audio detection
Alarm Actions:
Email, HTTP, TCP notification, SD card recording
Audio Input *4:
4x 3.5mm stereo jack, -51 to -38dB
Audio Output *4:
3.5mm stereo jack, monaural, 600Ω
External I/O Terminals *4:
4 alarm terminals (IN/OUT)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035
Other Standard:
NEMA-TS2
Power Source and Power Consumption:
PoE++ (IEEE 802.3bt), 37.8 W
Ambient Operating Temperature:
-50°C to 60°C (Power On: -30°C to 60°C)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Water and Dust Resistance:
IP66, Type 4X
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Dimensions:
Maximum diameter:φ167mm × 205 mm (H){φ6-9/16 inches × 8-1/16 inches (H)}; Dome radius SR 77.5 mm {SR 3-1/16 inches}; (excluding an attachment for the conduit portion and protruding parts)
Mass (approx:
Approx. 3 kg (without attachment)
Finish:
Aluminum die cast, polycarbonate dome
Other:
Tamper-resistant enclosure *5
Product Type:
PTZ
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE++
PoE Class:
6
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
6MP
Video Compression:
H.265, H.264, MJPEG
Audio Support:
Yes
IR Distance:
3.0m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
WDR:
WDR
Image Stabilization:
Yes
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
5-year warranty
Poe Power:
PoE++ (802.3bt)
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Mount Type:
Wall; Ceiling; Rack
Camera:
Title (OSD) On / Off, Up to 40 characters (alphanumeric characters, marks)
Operating Temp:
–50 °C to 60 °C * {–58 °F to 140 °F}
