i-PRO NVR-RL-1-16TB-V5 Rack-Mount Network Video Recorder
Overview
The NVR-RL-1-16TB-V5 is a 1U rack-mount surveillance server built on Lenovo enterprise architecture for branch offices, retail chains, and small-to-mid enterprise camera deployments. Intel Xeon 6-core processor and 16GB system RAM handle sustained multi-stream ingest without bottleneck. The 16TB single-drive storage (no RAID) supports continuous recording across a mid-sized camera fleet with standard retention windows. Windows 10 Pro pre-installed and factory-configured—deploy from the box without OS setup overhead. Dual 1GbE network ports sustain 150–250 Mbps typical recording performance; use 1 Gbps network for multi-camera concurrency. Hardware certified NDAA-compliant. Draws 300W maximum from a fixed, non-redundant power supply.
Compatibility
Integrates with any ONVIF-compliant IP camera system and VideoInsight software (license included). Works as edge or branch recording node with enterprise video management platforms via ONVIF Profile S/T. No RAID controller—storage operates as a single logical drive, suited for non-redundant branch roles where cost efficiency outweighs drive-level fault tolerance. Rear-facing HDD placement is a special-order configuration; confirm drive orientation with i-PRO before purchase to avoid delays.
Installation Notes
Requires standard 4-post 19-inch rack with 1U vertical space (1.7" height). Integrated rail kit included for tool-free mounting. Active cooling mandatory—not a fanless design. Operating environment: climate-controlled data center or server room. Lenovo 3-year on-site service warranty covers hardware failures but excludes third-party drive issues; use i-PRO or Lenovo-approved storage only to maintain warranty validity.
What's in the Box
- 1x NVR-RL-1 server unit (Windows 10 Pro pre-installed)
- 1x 16TB HDD (single drive, enterprise-class)
- Integrated 4-post rack rail kit
- Keyboard and mouse
