i-PRO NVR-R-1-60TB-V8 Rack-Mount Network Video Recorder
Overview
The i-PRO NVR-R-1-60TB-V8 is a 1U rack-mount network video recorder built for mid-to-large-scale surveillance deployments requiring extended retention and parallel multi-stream processing. It runs on an Intel Xeon 6-core processor with 32GB system memory and delivers 60TB total storage (40TB usable after RAID 5 overhead) — the core compute and storage capacity needed to sustain 150–300 Mbps recording rates across dozens of concurrent camera feeds in data center or enterprise security operations environments.
Compatibility
The NVR-R-1-60TB-V8 integrates with IP camera systems and VMS platforms supporting standard ONVIF protocols and Video Insight enterprise video management software (VI Enterprise Server Activation included at factory configuration). It accepts up to 2 PCIe Gen3 expansion slots for video capture cards or other enterprise hardware. Use with network infrastructure rated for sustained 1 Gbps throughput across both embedded 1GbE ports; larger deployments benefit from dedicated network segmentation. Suitable for organizations running Windows Server-based security operations centers or migrating legacy analog systems to IP infrastructure.
Installation Notes
Ships fully configured, tested, and ready for out-of-box deployment — no OS installation required. Requires 1U vertical rack space (height 1.67 inches, width 17.1 inches, depth 23.5 inches). Dual 600W power supplies support redundancy via separate circuit feeds; no single power point of failure. Four-post security rails included. Hard drives are rear-mounted; special-order rear-drive configurations require additional lead time (14+ business days). Keyboard and mouse not included; plan for external input devices. On-board TPM 2.0 supports drive encryption; NDAA hardware compliance verified at time of manufacture.
What's in the Box
- 1x i-PRO NVR-R-1-60TB-V8 fully configured and tested 1U rack server
- 1x H740 RAID controller (RAID 5 configured)
- 4x 3.5-inch enterprise HDD bays (3 populated with drives per model; 1 spare slot available)
- 1x M.2 high-speed SSD (OS drive)
- 2x four-post security mounting rails
- 2x 600W redundant power supplies
- iDRAC9 remote management card (pre-enabled)
