i-PRO NVR-R-1-36TB-V5 1U Rack Mount Network Video Recorder

Overview

The i-PRO NVR-R-1-36TB-V5 is a 1U rack-mount network video recorder designed for mid-to-large-scale surveillance deployments in data centers and centralized recording environments. This unit pairs an Intel Xeon 6-core processor (12 threads) with 32GB RAM and 36TB usable storage capacity — enough to sustain concurrent recording from dozens of IP cameras without throughput degradation. The system runs Windows Server 2022 Standard with pre-installed Video Insight Enterprise Server software, enabling Active Directory authentication and rapid search across full retention periods. Hardware is NDAA-compliant, meeting federal procurement standards for sensitive installations. The NVR-R-1-36TB-V5 ships fully configured and tested, ready for out-of-the-box deployment in enterprise environments.

Compatibility

This recorder integrates with any ONVIF-compliant IP camera — works across Axis, Hikvision, Dahua, i-PRO, and other standards-based camera lines. Dual 1GbE ports support sustained ingest at 150–300 Mbps (recommended rate) or up to 1 Gbps maximum throughput. Compatible with Windows Server 2022 domain environments and Video Insight management systems for centralized multi-site oversight. Storage subsystem uses up to four 3.5" enterprise SATA drives in RAID 5 configuration (H740 controller with onboard encryption and TPM 2.0) — protects against single-drive failure in continuous recording scenarios. Rear-drive configurations are special-order items requiring 14+ business days lead time.

Installation Notes

Form factor: 1U rack-mount (1.67" H × 17.1" W × 23.5" D); weighs 27 lbs. Includes 4-post security rails for standard 19" racks. Dual 600W power supplies provide redundancy — one fails, recording continues. iDRAC9 Enterprise enables remote diagnostics without onsite presence. No optical drive installed. Keyboard and mouse included as accessories. Server warranty excludes third-party hardware modifications — use only Dell-qualified enterprise drives for warranty coverage.

What's in the Box

• 1x i-PRO NVR-R-1-36TB-V5 1U rack server
• 2x 600W redundant power supplies
• 4-post security rails
• 1x keyboard
• 1x mouse
