HPE ML30 G11 6325P 1X32G 8SFF SSD NA SVR - P86726-005

HPE P86726-005 Compact Edge Server

Overview

The HPE P86726-005 is a compact single-socket server built on the Intel Xeon E processor family, configured with 32 GB of DDR5 ECC memory, and two 960 GB SATA SSDs in an 8-bay SFF chassis. This is a edge compute platform — not a consumer box — designed for organizations running small-scale video surveillance, security analytics, or distributed workloads where you cannot afford downtime and need error-correcting memory.

At its core, the P86726-005 delivers four physical cores at 3.5 GHz base clock with up to 128 GB maximum memory expandability. The dual 500W Platinum Flex Slot hot-plug power supplies mean redundant power without a separate UPS conversation — one supply fails, the other keeps the box running. The Intel Xeon E class (vs. Xeon W or higher) positions this as a cost-balanced edge box, not a workstation or high-core-count transcoding appliance.

Key Features

• Intel Xeon E processor, 4 cores, 3.5 GHz: Sufficient single-threaded performance for real-time video decode, encryption handoff, and basic analytics workloads. Four cores is the practical minimum if you're running a lightweight NVR or security appliance and don't want to compete with I/O for CPU cycles. Not a transcoding monster, but reliable for edge failover scenarios.
• 32 GB DDR5 ECC UDIMM at 4800 MT/s: DDR5 is the current standard for Xeon E systems — 4800 MT/s is the native rated speed. ECC (Error-Correcting Code) catches bit flips in RAM before they corrupt video frames or alarm logic. This matters if you're recording 24/7; silent data corruption is worse than a crash. Expandable to 128 GB if you add analytics or virtual machine workloads later.
• 2x960 GB SATA 6G Read-Intensive SSDs: Two drives give you local redundancy via RAID 1 mirroring through the controller below. 960 GB per drive = 1.92 TB raw capacity, or ~1.7 TB usable in mirrored configuration. Read-Intensive rating means these are tuned for surveillance playback and sequential workloads, not high-write-cycle enterprise logs. Right-sized for a branch office or remote facility NVR.
• HPE MR216i-p Gen11 storage controller: This is a RAID-capable PCIe card controller (not on-die). It supports RAID 0, 1, 5, 6, and 10. Handles the two SSDs natively. Can also accept additional SATA/SAS drives if you slot them into the remaining 6 empty SFF bays — future-proof for growth without a second controller.
• 8 SFF (Small Form Factor) drive bays: Two populated with the 960 GB SSDs; six bays empty and ready. SFF = 2.5-inch form factor. If surveillance footage growth outpaces your 1.9 TB, you can add two or three more SATA SSDs and span them into the RAID group without touching the box again. No hot-swap caddy learning curve — direct bay insertion.
• Dual 500W Platinum Flex Slot hot-plug power supplies: Platinum rating means 92%+ efficiency — less waste heat in a closet or small cabinet. Flex Slot means you can pull and replace a failed PSU without powering down. If one supply fails at 2 a.m., the second keeps your surveillance stream alive until you swap it during business hours. This is table stakes for unattended remote sites.
• Four PCIe Gen5 expansion slots: Gives you room for additional NICs, accelerators, or capture cards down the road. Gen5 means maximum throughput if you add a 100GbE adapter or offload encryption to a dedicated card. Most surveillance deployments won't fill these, but they're there if your workload grows.

Integration and Compatibility

The P86726-005 runs industry-standard x86 firmware and BIOS, so it accepts Linux (Ubuntu Server, RHEL, CentOS), Windows Server 2016 and later, or any Xeon-compatible hypervisor (VMware, Hyper-V, KVM). Many surveillance appliances ship as either bare-metal OS images or as OVA packages for virtual deployment — this platform supports both models. The dual Gigabit Ethernet (standard on ML30 Gen11) provides network connectivity; add a 10 GbE card in one of the PCIe slots if you need higher throughput into your NVR backend storage.

The three-year parts warranty (3/1/1 coverage: 3 years parts, 1 year labor, 1 year on-site) is typical for ML30 Gen11 units and covers the motherboard, PSUs, and cooling. Memory and SSD warranty follows their own vendor terms (usually shorter), so verify those separately before committing to a 24/7 deployment.

Frequently Asked Questions

Q: Can I use the P86726-005 as a primary NVR for a multi-site surveillance network?

A: Yes, if each site has fewer than 50–70 concurrent camera streams (depending on resolution and codec). The four Xeon E cores can handle real-time H.265 decode from 30–40 cameras at 1080p, but beyond that you'll hit CPU saturation. For large centralized NVRs, consider a higher core-count Xeon W or Platinum system.

Q: What's the warranty on the P86726-005?

A: The standard warranty is 3 years on parts, 1 year on labor, and 1 year on-site support. Extended coverage is available through HPE Service Navigator.

Q: Does the P86726-005 come with a RAID controller pre-configured?

A: Yes — the HPE MR216i-p Gen11 controller is installed and ready to manage the two 960 GB SSDs. You can configure them as RAID 1 (mirroring) out of the box for redundancy, or initialize them separately if you prefer two independent volumes.

Q: Can I add more storage without replacing the SSDs?

A: Yes. You have six empty SFF bays. Populate them with additional SATA SSDs or SAS drives and extend the RAID group through the controller. No second controller needed unless you exceed the MR216i-p's drive limit (typically 16 drives).

Q: Is the P86726-005 suitable for virtualization?

A: Yes, it supports VMware vSphere, Microsoft Hyper-V, and KVM. Four cores is on the light side for heavy VM consolidation, but it's adequate for 4–6 lightweight surveillance appliance VMs or a small failover cluster.

Q: What operating systems are supported?

A: Linux (Red Hat, CentOS, Ubuntu Server), Windows Server 2016 and later, and any x86-compatible hypervisor. Consult your appliance vendor's support matrix for certified OS versions.

Jerry Tildsen

I spec the P86726-005 into edge surveillance and failover roles where you need a compact, redundant appliance that won't keel over if one power supply fails at 3 a.m. Four Xeon E cores and 32 GB DDR5 ECC are plenty for a 30–40 camera site or a lightweight analytics cluster at a branch facility. The dual hot-plug 500W PSUs are the killer feature here — Platinum-rated efficiency and automatic failover without a UPS conversation.

Technical Highlights:

• Intel Xeon E 4-core @ 3.5 GHz: Handles real-time H.265 decode from 30–40 concurrent 1080p streams without choking. Clock speed isn't the issue; it's the core count. Four cores is the threshold where you avoid CPU contention between video decode, encryption, and system I/O on a 24/7 appliance.
• 32 GB DDR5 ECC at 4800 MT/s: ECC catches bit flips before they corrupt recorded frames — critical on surveillance systems where silent data corruption is worse than a crash. DDR5 @ 4800 MT/s is native speed for Xeon E, no overclocking tricks. Expandable to 128 GB if you add VMs or in-memory analytics later.
• Dual 500W Platinum Flex Slot PSUs: Redundant power with automatic failover. Platinum efficiency (92%+) means less heat dissipation in a closet or small cabinet. Flex Slot lets you swap a failed PSU without a power-down. One supply failure doesn't bring down your surveillance stream.
• 2x960 GB SATA SSDs + 6 empty SFF bays: 1.9 TB raw in RAID 1 configuration covers 2–3 weeks of 30–40 camera footage at mixed resolution. Six empty bays give you expansion room — add more SSDs or SAS drives without replacing existing media or touching the controller.

Deployment Considerations:

• Four cores means you're capped at 30–40 concurrent 1080p streams before CPU saturation forces you to upgrade to a higher core-count Xeon W or Platinum system. Test your specific codec (H.265 vs. H.264) and resolution mix before committing to large-scale deployment.
• The 1.9 TB raw SSD capacity sounds tight if you're planning 24/7 retention on 40+ cameras — that's roughly 2 weeks at mixed 1080p/2MP. Plan for external NAS or tiered storage if retention requirements extend beyond 30 days.

Use the P86726-005 for branch office NVRs, edge failover appliances, or small analytics clusters where you want redundancy, quiet operation, and zero downtime on power supply loss. Not a datacenter box, but perfect for unattended remote sites where a technician visit costs more than a dual-PSU system.
