HPE P65412-B21 OCP Cable Kit

Overview

The HPE P65412-B21 is an OCP (Open Compute Project) cable kit designed specifically for the HPE ProLiant DL20 Gen11 server series, supporting both 2LFF and 4SFF chassis configurations. This kit provides the necessary cabling to connect OCP network adapters and storage devices, ensuring proper data flow and power distribution within the server. It's essential for deployments requiring specific OCP mezzanine card integration or advanced storage topologies not covered by standard server cabling.

Compatibility

This cable kit is designed exclusively for the HPE ProLiant DL20 Gen11 server platform. It is compatible with DL20 Gen11 servers configured with either the 2 Large Form Factor (LFF) or 4 Small Form Factor (SFF) drive bays, provided they utilize an OCP mezzanine slot for network or storage expansion.

Installation Notes

Installation requires opening the server chassis and carefully routing cables to their respective connectors on the motherboard and OCP adapter. Ensure the server is powered off and properly grounded before beginning. Refer to the HPE ProLiant DL20 Gen11 server documentation for detailed cable routing diagrams specific to your OCP adapter and chassis configuration to avoid signal integrity issues or improper connections.
