HPE DL20 GEN11 EXT OCP CBL KIT - P65411-B21

HPE P65411-B21 HPE DL20 GEN11 EXT OCP CBL KIT

Overview

The HPE DL20 GEN11 EXT OCP CBL KIT, model P65411-B21, is designed to facilitate the installation of an OCP (Open Compute Project) network adapter into HPE ProLiant DL20 Gen11 servers. This kit provides the necessary cabling and components to ensure a secure and functional integration, critical for maintaining network connectivity in demanding environments such as data centers or surveillance operations where reliable network adapter performance is paramount. It addresses the specific physical and electrical interface requirements for OCP adapters within the DL20 Gen11 chassis.

Compatibility

This cable kit is specifically designed for the HPE ProLiant DL20 Gen11 server series. It is intended for use with OCP network adapters that conform to the OCP specifications and are designed to be installed in the dedicated OCP slot within the DL20 Gen11 chassis. Compatibility is limited to this server generation and OCP adapter form factor; it is not compatible with standard PCIe network cards or other server models.

Installation Notes

Installation requires careful attention to the server's internal layout. The process involves removing the OCP slot blank, which includes a blank screw and the blank itself; these should be retained for future use. The power must be completely disconnected from the server before proceeding, meaning each power cord must be unplugged from both the power source and the server. The kit includes friction rack rail components, indicating the server is intended for rack mounting. Ensure all connections are secure to prevent intermittent network issues.

What's in the Box

• 1x OCP Slot Blank Screw
• 1x OCP Slot Blank
• 1x Friction Rack Rail
