HPE DL20 G11 6333P 1X32G 4SFF SSD NA SVR - P86810-005

HPE P86810-005 1U Rack Server for Surveillance Infrastructure

Overview

The HPE P86810-005 is a compact 1U rack server purpose-built for distributed surveillance deployments, small-to-medium video analytics workloads, and edge compute in monitoring environments. Built on the HPE ProLiant DL20 Gen11 platform, the P86810-005 pairs a 6-core Intel Xeon 6333P processor with 32GB of single-socket UDIMM memory and 4 small-form-factor (SFF) drive bays, making it suitable for on-premises NVR duty, local AI inference, or hybrid surveillance architectures where you need compute density without enterprise-scale power draw.

Key Features

• 6-Core Intel Xeon 6333P Processor: Single-socket design limits thermal overhead and power consumption compared to dual-socket systems, while delivering sufficient single-threaded performance for real-time video transcoding and light analytics workloads. Critical for facilities that run 24/7 surveillance on constrained power budgets.
• 32GB DDR5 Memory (1x32GB UDIMM): Single-DIMM configuration leaves one memory slot free — you can upgrade to 64GB without removing the original module. 32GB is the practical floor for smoothly handling 30–50 camera streams at 1080p or 2MP resolution with local recording and basic metadata extraction.
• HPE MR408i-o Gen11 Storage Controller with 4GB Cache: Attached via OCP SPDM over 8-lane PCIe Gen5 connection. The on-controller cache buffers write spikes from multi-stream simultaneous recording, reducing latency during peak I/O. 4GB is sufficient for most mid-scale surveillance use cases where you're not running parallel database transactions.
• 4 Small-Form-Factor (SFF) Drive Bays with 2x960GB SATA SSDs: Pre-populated with two 960GB drives for ~1.9TB usable capacity (accounting for RAID 1 mirroring or controller overhead). Two empty bays remain for future expansion — typical deployments add a second pair for hot-standby failover or separate recording/analytics tiers. SATA SSD is the right choice here: lower cost than NVMe, adequate throughput for surveillance bitrates, and mature in datacenter reliability.
• Dual 500W Platinum PSUs with Hot-Plug Support: Redundant power supplies eliminate single-point-of-failure risk during electrical events. Platinum efficiency (92%+) minimizes wasted heat in enclosed racks. 500W per supply is conservative for this CPU/memory/drive configuration, providing headroom for transient load spikes (e.g., simultaneous disk scrubbing and analytics) without throttling.
• 4x1GbE Network Interfaces: Four Gigabit ports allow segregation of management, recording, and inter-server heartbeat traffic. In surveillance architectures with separate management and data VLANs, this is essential. One port can be dedicated to out-of-band management without consuming bandwidth reserved for video streams.
• 1U Form Factor with 15.05-inch Depth: Fits standard 19-inch EIA racks. The compact 15.05-inch depth matters in shallow wall-mounted cabinets common in branch offices, retail locations, or warehouses — verify your rack depth before ordering to avoid cable-routing headaches.
• TPM 2.0 and Intrusion Detection Kit: TPM 2.0 enables firmware attestation and secure boot, reducing boot-time malware risk. Intrusion Detection Kit includes a physical tamper switch inside the chassis — logs unauthorized access attempts in HPE's iLO management interface, useful for compliance audits in regulated facilities.
• 3-Year Manufacturer Warranty: HPE's standard 3/3/3 coverage (3 years parts, 3 years labor, 3 years on-site) provides predictable support windows. For surveillance deployments running continuous duty, factor in on-site replacement for failed components — 8-hour or 4-hour response tiers are available as add-ons.

Integration and Compatibility

The P86810-005 runs standard Linux or Windows Server distributions used in surveillance NVR platforms (Milestone Husky, Vivotek NVR, Genetec AutoVu, or custom Python-based systems). The OCP slot and PCIe Gen5 interface support optional accelerators — NVIDIA H264/H265 encoding cards for real-time video compression, or TPU modules for on-device object detection. iLO (Integrated Lights-Out) remote management allows headless deployment and out-of-band console access even if the OS hangs. Single-socket architecture simplifies OS licensing (many enterprise VMS products charge per-socket) and reduces complexity in failover clusters — pair two P86810-005 units with shared storage for cold-standby or active-active recording redundancy.

What's in the Box

Standard HPE ProLiant DL20 Gen11 package includes: server chassis with two pre-installed 960GB SATA SSDs, dual 500W Platinum PSU modules, bezel, mounting slides, one 1GB iLO Advanced license (1-year), and HPE iLO quick-start card. AC power cables (qty. 2) are typically included; verify with your supplier if you require region-specific power connectors.

Frequently Asked Questions

Q: What is the maximum storage capacity of the P86810-005?

A: The server supports 4 SFF (2.5-inch) SATA or SAS drive bays. Maximum capacity depends on drive density: with four 2TB drives, you can reach 8TB raw capacity. The standard configuration ships with 2x960GB SATA SSDs, leaving two bays for expansion.

Q: Can I upgrade the processor or memory after purchase?

A: Memory is user-upgradeable — the single 32GB UDIMM can be replaced with a 64GB module, or you can add a second 32GB/64GB UDIMM to the empty slot. The processor (Xeon 6333P) is soldered to the motherboard and cannot be replaced. Upgrades must be done at initial order.

Q: Does the P86810-005 support RAID configuration?

A: Yes. The HPE MR408i-o controller supports RAID 0, 1, 5, 6, and 10. The standard configuration (2x960GB) can run RAID 1 mirroring for redundancy, or you can configure as RAID 5 once all four bays are populated.

Q: What is the power consumption of the P86810-005?

A: Typical operating load is 150–200W at standard utilization (recording + basic analytics). Peak power draw during simultaneous disk operations and CPU-intensive tasks can approach 300–350W. The dual 500W PSUs provide significant overhead and ensure stable operation during transient spikes.

Q: Is the P86810-005 suitable for outdoor or harsh environments?

A: No. This is a standard rack-mount server rated for datacenter/office environment operation (0–40°C typical). For outdoor surveillance compute, you would need an industrial-grade edge appliance with IP65/IP67 enclosure. However, the P86810-005 can be deployed in an outdoor-rated cabinet with climate control.

Q: What warranty does the P86810-005 come with?

A: HPE provides a 3-year manufacturer warranty covering parts and labor (3/3/3 standard). Extended warranties and on-site response options can be added at purchase or during the warranty period.

James Everett

The P86810-005 is the sensible pick if you're deploying a distributed surveillance architecture — multiple smaller on-premises recorders instead of one monolithic data-center NVR. The 6-core Xeon 6333P and 32GB RAM combination handles 30–50 concurrent camera streams without breaking a sweat, and the dual 500W Platinum PSUs mean you're not racing the clock when a power supply fails at 2 AM on a Saturday. I've deployed dozens of these in branch-office and retail environments where the alternative was a bloated multi-socket server drawing 1000W+ at idle.

Technical Highlights:

• 6-Core Single-Socket Xeon 6333P: Delivers ~170 GHz aggregated compute. More than adequate for simultaneous H.265 transcoding of 30–40 1080p streams plus light object detection (people, vehicle, license-plate) without maxing CPU. Avoids licensing penalties that many VMS products impose on dual-socket systems.
• 32GB DDR5 with One Empty DIMM Slot: 32GB is the practical baseline for 50+ camera deployments. Future-proof: you can add a second DIMM on-site without downtime if retention periods expand or analytics load grows — no motherboard replacement required.
• HPE MR408i-o with 4GB Cache + PCIe Gen5: The 4GB write-back cache smooths I/O latency during peak recording windows. OCP slot and Gen5 PCIe opening allow you to plug in an NVIDIA H264/H265 accelerator card later (e.g., Quadro T600) for GPU-driven transcoding, saving CPU cycles for analytics.
• Dual 500W Platinum Efficiency PSUs: Redundant power is non-negotiable in surveillance. Platinum efficiency burns less heat in enclosed racks — matters in small wiring closets. 500W per supply is conservative, so you have headroom if you add drive expansion or future compute accelerators.

Deployment Considerations:

• The single-socket design is a feature, not a limitation — simplifies licensing and reduces complexity in failover pairs. But if you need >16 cores, you'll need to step up to a dual-socket DL380 or similar, which doubles power and cost.
• The 4 SFF bays fill quickly. Two 960GB drives (standard) plus two empty bays means you're committed to populating those bays within a year if you're recording 24/7 at any meaningful bitrate. Plan your drive expansion budget upfront.
• The 15.05-inch depth is shallow — verify your rack depth before install. Some wall-mounted shallow cabinets can accommodate this, but SANs and managed switches often need deeper chassis. Measure twice.

Deploy the P86810-005 where you need reliable local recording with some compute headroom, but avoid it if you're chasing multi-petabyte storage or need more than 100 concurrent streams on a single box. For regional distribution centers, corporate branches, and retail chains with 30–50-camera footprints, this is the proven choice.
