Type:
Bullet
Features:
AI
Features:
DeepinView
Frame Rate:
High
Sensor Type:
1/1.8" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
0.0005 Lux color / 0 Lux IR
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter;Blue glass module to reduce ghost phenomenon
Focal Length & FOV:
2.8-12mm (114.5°-41.8° H), 8-32mm (42.5°-15.1° H)
Focus:
Auto,Semi-auto,Manual
Iris Type:
P-iris
Aperture:
2.8 to 12 mm: F1.2 to F2.5;8 to 32 mm: F1.7 to F1.73
DORI:
D:150m / O:60m / R:30m / I:15m
Supplement Light Type:
IR
Supplement Light Range:
2.8 to 12 mm: 50 m;8 to 32 mm: 100 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Model Specification:
Detection, Classification, Mixed Models
Main Stream:
2688×1520 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Fourth Stream:
25-30 fps, 704×576 to 640×480
Fifth Stream:
25-30 fps (704×576, 640×480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
E-PTZ:
Support Patrol and Auto Tracking settings
Audio Bit Rate:
64 Kbps (G.711), 16 Kbps (G.722.1), 32-192 Kbps (MP2L2
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Type:
Mono sound
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (S/G/T/M), ISAPI, SDK, ISUP
User/Host:
32 users; 3 levels
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Image Parameters Switch:
Yes
Image Settings:
Rotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule,Alarm Trigger
Wide Dynamic Range (WDR:
140 dB
Image Enhancement:
BLC,HLC,3D DNR,Distortion Correction,Defog
SNR:
≥ 52 dB
Privacy Mask:
8 programmable polygon privacy masks
Image Stabilization:
EIS
Picture Overlay:
Logo overlay 128×128 24-bit BMP
Video Outputs:
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface:
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board Storage:
microSD/microSDHC/microSDXC up to 1TB
Audio Support:
With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector
Alarm:
2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485:
1 RS-485 (half duplex)
Reset Key:
Yes
Power Output:
With -Y: 12 VDC, max. 100 mA
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibrat
Smart Event:
scene change detection,audio exception detection,defocus detection
Linkage:
FTP, NAS, email, alarm, recording, capture, alert
Multi-Target-Type Detection:
Multi-target detection: human, face, vehicle
Face Capture:
120 faces, 40 pics/frame, 10 pics/sec, ±60° pan, ±30° tilt
Face Comparison:
10 libraries, 30,000 faces each
Perimeter Protection:
Line crossing, intrusion, region entrance/exit
People Counting:
Real-time people counting with entry/exit/pass-by tracking
Queue Management:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 2 detection modes: regional people queuing-up, waiting time detection;Generates reports to compare the efficiency of different queuing-ups and display the
Heat Map:
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area., Two report types are available, space heat map and time heat map line chart.
Hard Hat Detection:
Detects 30 targets, 4 shield regions
Metadata:
Intrusion detection, line crossing, face capture
Regional People Counting:
8 detection regions, 3 modes
On/Off Duty Detection:
8 detection regions, 2 modes
Power Type:
PoE
Material:
Aluminum alloy body
Dimension:
Ø144 mm × 347 mm; Ø140 mm × 351 mm
Package Dimension:
405 mm × 190 mm × 180 mm (15.9" × 7.5" × 7.1")
Weight:
Approx. 1950 g (4.2 lb.)
With Package Weight:
Approx. 3070 g (6.7 lb.)
Storage Conditions:
-30°C to 60°C, ≤95% humidity
Startup And Operating Conditions:
-40°C to 60°C
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
General Function:
Heartbeat, mirror, password protection, one-key reset
Heater:
Yes
Device Management:
Alarm box expansion (6 input, 6 output)
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment Rating:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013,IK10: IEC 62262:2002
Anti-Corrosion Protection:
-Y: NEMA 4X (NEMA 250-2018)
Automotive And Railway:
EN50121-4
Other:
PVC FREE
CC:
Common Criteria, Assurance Level: EAL2 + ALC_FLR.2
Product Type:
Bullet
Connectivity:
Wired
Night Vision:
IR
PoE Class:
4
Form Factor:
Bullet
IP Rating:
IP67, NEMA 4X
Vandal Rating:
IK10
Max Channels:
20
Resolution:
4MP
IR Distance:
164m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Max Resolution:
2560x1440
Lens Type:
Varifocal
Image Sensor Size:
1/1.8" progressive scan CMOS
Horizontal Fov:
114.5°
Vertical Fov:
59.3°
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
Package Contents:
Face capture: detects up to 120 simultaneous faces with 7-feature extraction; captures 40 face images per frame at 10 fps upload; Multi-target counting: people counting with flow direction analysis, queue management across 8 regions, hard hat detecti
